Product Details:
Place of Origin: Shaanxi, China (Mainland)
Brand Name: KACISE
Model Number: K-IMU-400
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/Pieces
Price: Negotiable
Packaging Details: carton or customers requests available
Delivery Time: 5 working days after payment
Payment Terms: L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 1000 Piece/Pieces per Week negotiable
Contact Now
Detailed Product Description
Input Voltage: 9~36 VDC Input Current: ≤ 100 MA
Output Mode: RS-422 Baud Rate: 115200bps
Output Data Rate: 200Hz Output Data Format: 16-bit Twos Complement
High Light:

inclinometers and tilt sensors

,

electronic tilt sensor

RS485/RS232 Output Inertial Measurement Unit for Navigation Guidance System

Features



☆Digital RS485/RS232 output

☆Whole temperature range compensation

☆Nonlinear correction, Cross coupling correction

☆impact resistance, vibration performance


Application



☆ System for vehicle rollover

☆ Navigation guidance system


S  Specification



Type K-IMU-400
Electric character
Input voltage 9~36 VDC
Input current ≤ 100 mA
Output Mode RS-422
Baud Rate 115200bps
Output Data Rate 200Hz
Output Data format 16-bit twos complement
Performance index
Sensor Gyroscope accelerometer
Range ±150 °/s ±10g
Bandwidth ≥50 Hz
Resolution (°/s) ≤ 0.04°/s 0.005g
Nonlinear (%FS) ≤ 0.5% Fs ≤1% Fs
Bias ±0.2°/s 0.02g
Bias stability ≤0.05°/s ≤0.002g
Start-up time (ms) ≤ 1 s
Environmental characteristics
Temperature (°C) -40~70
Storage Temperature (°C) -40~125
Resistant to shock 2000g
Physical Characteristics
Weight (g) 250
Dimensions 55×55×33mm



Dimensions

RS485 / RS232 Output Inclinometer Sensor Inertial Measurement Unit 0RS485 / RS232 Output Inclinometer Sensor Inertial Measurement Unit 1RS485 / RS232 Output Inclinometer Sensor Inertial Measurement Unit 2
