High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size

High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size

  • High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size
  • High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size
  • High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size
  • High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size
High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size
Product Details:
Place of Origin: China (Mainland)
Brand Name: Kacise
Certification: Intrinsically safe mode E, RoHS; CE
Model Number: CLS-X078
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: USD 90-110
Packaging Details: each unit has individual box and all boxes are packed in standard packages or customers requests available
Delivery Time: 5-8 work day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal
Supply Ability: 10 pieces per week
Contact Now
Detailed Product Description
Max Pressure Range: 5.0Bar(72psi) Weight: 0.15kg Typical(dependent On Thread Size)
Body: Brass Probe: PTFE
Operating Temperature: -40℃ To +130℃ Storage Temperature: -50℃ To +140℃
Max. Load Current: 1.0A(sink) Or 20mA(source) Supply Voltage: 9-32VDC
High Light:

high accuracy pressure sensor

,

piezoresistive pressure transmitter





Capacitance Coolant Level Switch CLS-X078





Capacitance PTFE Brass Mechanically Operated Switches Coolant Level Switch Send Alarm Signal



Product Description

Introduction

The CLSX078 is an active device which is designed to give an alarm signal if liquid falls below / rises above a preset level. It willonly signal an alarm after a few seconds of low/high level to eliminate false alarms due to turbulence. The fact that the CLSX078has no moving parts and incorporates a built in delay means it is ideal in

applications where mechanically operated switches mistrigger due to vibration and liquid turbulence. Different

thread options are available on request.

High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size 0


Feature

  • Brass body
  • PTFE probe
  • VIton FKM seals.
  • 30% Glass filled Nylon 6 connector
  • Bibra seal 516 request
  • 4 way DIN 72 585 connection

Specification

Spec. Value
Max pressure range 5.0Bar(72psi)
Weight 0.15kg typical(dependent on thread size)
Body Brass
Probe PTFE
Terminals Brass, Tin Plated
Operating temperature -40℃ to +130℃
Storage temperature -50℃ to +140℃
Max. load Current 1.0A(sink) or 20mA(source)






High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size 2



Ordering information




High Precision Pressure Sensor Capacitance Coolant Level Switch Small Size 5

Company Information

Xi'an Kacise is qualified with ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof certificates, etc. which ensure that our products comply with international standards.

We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. Based on experienced technical and management personnel, through efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.

Currently, Kacise sensors have already been exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regard “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.


FAQ

Q: What information need to be provided to choose a suitable level switch?

A: 1.Medium 2.Power supply 3.Output 4.Thread size 5.Alarm delay time 6.Output state

Q: Are you a trade company or a manufacturer?

A: We are an ISO approved manufacturer specialized in level and flow measuring instruments. OEM & ODM service are available.

Q: What is your MOQ?

A: To start our cooperation, sample order is acceptable.

Q: What is your delivery date?

A: The delivery date is about 3-15 working days after receipt of payment.

Q: What is your payment terms?

A: For mass production order, it is 30% deposit in advance and 70% balance before shipment.
