| Place of Origin: | China (Mainland) |
| Brand Name: | Kacise |
| Certification: | ISO 9001-2008,GJB 9001B-2009,CE |
| Model Number: | RBA500 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | each unit has individual box and all boxes are packed in standard packages or customers requests available |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal |
| Supply Ability: | 500 Pieces per Week |
| Input Voltage: | +14 To +16 VDC | Case Material: | Stainless Steel |
|---|---|---|---|
| Operating Temperature Range: | -55 To +105°C | Application: | GPS Navigation Systems |
| Power: | <75 MW @ +15 VDC | Theory: | Capacitance Sensor,Acceleraiton Angle Angular Velocity Magnetic Field Air Pressure Height |
| High Light: | Gps Navigation MEMS Accelerometer,Stainless Steel MEMS Accelerometer,80Hz/G Accelerometer Sensor |
||
Product Introduction
An accelerometer is a tool that measures proper acceleration. Such forces may be static, like the continuous force of gravity or, as is the case with many mobile devices, dynamic to sense movement or vibrations. Acceleration is the measurement of the change in velocity, or speed divided by time.The output of the Accelerex accelerometer is also thermally compensated through the use of an internal temperature sensor and Honeywell-supplied coefficients; when integrated over time, delta Velocity is directly provided to the user's system.
Features
1. High Accuracy
2. GPS navigation
Product Specification
| Input range |
±70 g
|
|
One year repeatability
|
<4 mg
|
|
Scale Factor
|
80 Hz/g
|
|
One year repeatability
|
<450 ppm
|
|
Axis misalignment
|
<12 mrad
|
|
Operating temperature range
|
-55 to +105°C
|
|
Vibration
|
20g, peak, DC-2000 Hz
|
|
Input voltage
|
+14 to +16 VDC
|
|
Power
|
<75 mW @ +15 VDC
|
|
Case material
|
Stainless Steel
|
Parameters
Compamy Information
Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards. We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality. Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.
FAQ
1. What is the working principle of accelerometer?
A: The basic underlying working principle of an accelerometer is such as a dumped mass on a spring. When acceleration is experienced by this device, the mass gets displaced till the spring can easily move the mass, with the same rate equal to the acceleration it sensed.
2. Q: What information need to be provided to choose the suitable model?
A: Application field, measuring range, output, accuracy, connection and other related parameters.
3. Q: Are you a trade company or a manufacturer?
A: We are an ISO approved manufacturer specialized in level and flow measuring instruments.
OEM & ODM service are available. Welcome to visit us.
4. Q: What is your MOQ?
A: To start our cooperation, sample order is acceptable.
5. Q: What is your delivery date?
A: The delivery date is about 3-15 working days after receipt of payment.
6. Q: What is your payment terms?
A: We support T/T, PayPal and Trade Assurance.
For mass production order, it is 30% deposit in advance and 70% balance before shipment.
7. Q: What is Trade Assurance payment method:
A: It’s a free service which can protect your orders from payment to delivery.
And we now have USD104,000.00 of caution money to assure your orders.
8. Q: Do you have a warranty?
A: Yes, we have the warranty of 12 months.
