| Place of Origin: | CHINA |
| Brand Name: | kacise |
| Certification: | CE |
| Model Number: | KRC601 |
| Minimum Order Quantity: | 0-100 |
|---|---|
| Price: | $0-$500 |
| Packaging Details: | Common package or custom package |
| Delivery Time: | 3-10days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200pcs/day |
| Measuring Principle: | Constant Voltage Method | Range Range: | 0ー2.000 Mg/L (HClO) |
|---|---|---|---|
| Resolution: | 0.001 MGL | Precision: | ± 5% Or ± 0.05 Mg/l, ± 0.5 °C |
| Calibration Function: | Two-point Calibration | Working Pressure: | < 0.1 Mpa |
| High Light: | Constant voltage chlorine residual sensor,Drinking Water residual chlorine sensor,Pom Shell residual chlorine sensor |
||
Used in drinking water treatment plant, canning plant, drinking water distribution network, swimming pool, cooling circulating water, water treatment project, etc. .
| Model number | KRC601 |
|
Measuring principle |
Constant voltage method |
| Range Range | 0ー2.000 mg/L (HClO) |
| Resolution | 0.001 MGL |
| Precision | ± 5% or ± 0.05 mg/l, ± 0.5 °C |
|
Calibration function |
Two-point calibration |
| Working pressure | < 0.1 mpa |
|
The pH range of the medium |
4 ~ 9 ph |
|
Temperature compensation |
Automatic temperature compensation (PT1000) |
| Signal output | RS-485(Modbus/RTU) |
| Shell material | Pom, polytetrafluoroethylene |
|
Operating temperature |
5 ~ 50 °C |
| Installation mode | Circulation Pool installation |
| Dimensions | 30 × 233 mm |
| Velocity of flow | 30 ~ 60 L/h |
| Response time | < 30s |
| Power consumption | 0.2W@12V |
| Power supply | 12 ~ 24 VDC |
| Protection level | IP68 |
3.Dimensional Drawing
Note: Sensor Connector is M16-5 core waterproof connector
