| Place of Origin: | Shaanxi, China |
| Brand Name: | GXSENSORS support OEM |
| Model Number: | ZIGBEE Fuel level Sensor |
| Price: | $90.00 - $200.00/pieces |
|---|---|
| Packaging Details: | each unit has individual box and all boxes are packed in standard packages or customers requests available |
| Supply Ability: | 1000 Piece/Pieces per Week negotiable |
| Usage: | GPS, Temperature Sensor | Theory: | Other |
|---|---|---|---|
| Output: | Wireless Battery | Name: | Economical Digital ZIGBEE Fuel Level Sensor For Bus |
| Measure Range: | 0~3m Diesel | Measure Precision: | 0.5%F.S |
| Power Supply: | 3.6VDC Battery Or 10VDC~35VDC External Power Supply | Defend Grade: | IP65 |
| Working Temperature: | -25℃~85℃. | Storage Temperature: | -25℃~85℃. |
| Interface Type: | NPT1 | Timing Work Time: | 5 Minute ~ 1000 Minute(can Set) |
| Port: | Shanghai Or Other |
Economical Digital ZIGBEE Fuel level Sensor for Bus
1. System Summarize of Economical Digital ZIGBEE Fuel level Sensor for Bus
The “Liquid height measuring system in GPRS communicate mode” include “Liquid height measuring terminal equipment in GPRS communicate mode”, “Server Management Software” and “Configuration Line”. It is used for timing measure liquid height value, temperature value, longitude and latitude data, date and time information and show these value in the “Server Management Software”.
2. “Terminal” Structure Drawing of Economical Digital ZIGBEE Fuel level Sensor for Bus
GXPS609(GPRS) terminal structure drawing: as picture one
The back of GXPS609(GPRS) terminal: as picture two
Parameters of Economical Digital ZIGBEE Fuel level Sensor for Bus
| Measure Range | 0~3m diesel |
| Measure Precision | 0.5%F.S |
| Power Supply Way | 3.6VDC battery or 10VDC~35VDC external power supply. |
| Defend Grade | IP65 |
| Work Temperature | -25°C~85°C |
| Storage Temperature | -25°C~85°C |
| Communication Frequency | GSM/GPRS 850/900/1800/1900MHz |
| Interface Type | NPT1 |
| Timing Work Time | 5 minute ~ 1000 minute(can set) |
| Append Function | Append Function |
