Name: Dwyer MS Series Magnesense Differential Pressure Transmitter
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: MS-021 MS-111-LCD
Price: 152.00 USD
Availability: InStock

Home > products > Precision Pressure Sensor >

Dwyer MS Series Magnesense Differential Pressure Transmitter

Differential Pressure Transmitter

Magnesense Pressure Transmitter

Dwyer MS Series Pressure Transmitter

Brand Name:

Dwyer

Certification:

Model Number:

MS-021 MS-111-LCD

Request A Quote

Dwyer MS Series Magnesense Differential Pressure Transmitter

Product Details

Accuracy:

±1%

Stability:

±1% FS/year

Temperature Limits:

0 To 150°F (-18 To 66°C)

Pressure Limits:

1 Psi Maximum, Operation; 10 Psi, Burst

Power Requirements:

10 To 35 VDC (2-wire); 17 To 36 VDC Or Isolated 21.6 To 33 VAC (3-wire)

Output Signals:

4 To 20 MA (2-wire); 0 To 5 V, 0 To 10 V (3-wire)

Highlight:

Differential Pressure Transmitter

Magnesense Pressure Transmitter

Dwyer MS Series Pressure Transmitter

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

Testo 330-2 LL Pro Flue Gas Analysis Kit Colour Graphic Display and 600 G Display Function

Get Best Price

Honeywell BW Solo Lite BWS2-S-Y Sulfur Dioxide (SO₂) Gas Detector

Get Best Price

Fluke 15B+ and 17B+ Digital Multimeters with Test Leads and Accessories

Get Best Price

Keyence AP-31A AP Series 12–24V DC Pressure Sensor / Pressure Switch

Get Best Price

86--17719566736

Contact Now

Product Description

Dwyer MS Series Magnesense Differential Pressure Transmitter

Key Specifications

Accuracy	±1%
Stability	±1% FS/year
Temperature Limits	0 To 150°F (-18 To 66°C)
Pressure Limits	1 Psi Maximum, Operation; 10 Psi, Burst
Power Requirements	10 To 35 VDC (2-wire); 17 To 36 VDC Or Isolated 21.6 To 33 VAC (3-wire)
Output Signals	4 To 20 MA (2-wire); 0 To 5 V, 0 To 10 V (3-wire)

Product Overview

The Dwyer MS Series Magnesense Differential Pressure Transmitter combines versatility and precision for industrial pressure and air velocity monitoring. Leveraging patented magnetic sensing technology, this transmitter delivers long-term reliability with field-selectable ranges, adjustable outputs, and optional LCD displays—making it an ideal single solution for diverse pressure and flow applications.

Applications

HVAC Systems:

Filter pressure drop monitoring
Air velocity measurement with Pitot tubes
Duct static pressure control

Industrial Processes:

Blower vacuum sensing
Cleanroom positive pressure maintenance
Fluid amplifier pressure monitoring

Building Automation:

Room pressure differential control
Fire damper position indication

Available Models

Model	Description
MS-021	Differential pressure transmitter, 4-20 mA output, selectable range ±0.1", 0.25", 0.5" w.c. (±25, 50, 100 Pa), wall mount.
MS-021-LCD	Differential pressure transmitter, 4-20 mA output, selectable range ±0.1", 0.25", 0.5" w.c. (±25, 50, 100 Pa), wall mount, with LCD.
MS-111	Differential pressure transmitter, 4-20 mA output, selectable range 1", 2", 5" w.c. (250, 500, 1250 Pa), wall mount.
MS-111-LCD	Differential pressure transmitter, 4-20 mA output, selectable range 1", 2", 5" w.c. (250, 500, 1250 Pa), wall mount, with LCD.
MS-112	Differential pressure transmitter, 4-20 mA output, selectable range 1", 2", 5" w.c. (250, 500, 1250 Pa), duct mount.
MS-112-LCD	Differential pressure transmitter, 4-20 mA output, selectable range 1", 2", 5" w.c. (250, 500, 1250 Pa), duct mount, with LCD.
MS-121	Differential pressure transmitter, 4-20 mA output, selectable range 0.1", 0.25", 0.5" w.c. (25, 50, 100 Pa), wall mount.
MS-121-LCD	Differential pressure transmitter, 4-20 mA output, selectable range 0.1", 0.25", 0.5" w.c. (25, 50, 100 Pa), wall mount, with LCD.
MS-122	Differential pressure transmitter, 4-20 mA output, selectable range 0.1", 0.25", 0.5" w.c. (25, 50, 100 Pa), duct mount.
MS-122-LCD	Differential pressure transmitter, 4-20 mA output, selectable range 0.1", 0.25", 0.5" w.c. (25, 50, 100 Pa), duct mount, with LCD.
MS-131	Differential pressure transmitter, 4-20 mA output, selectable range 10" w.c. (2 kPa), wall mount.
MS-131-LCD	Differential pressure transmitter, 4-20 mA output, selectable range 10" w.c. (2 kPa), wall mount, with LCD.
MS-141	Differential pressure transmitter, 4-20 mA output, selectable range 15" w.c. (3 kPa), wall mount.
MS-141-LCD	Differential pressure transmitter, 4-20 mA output, selectable range 15" w.c. (3 kPa), wall mount, with LCD.
MS-151	Differential pressure transmitter, 4-20 mA output, selectable range 25" w.c. (5 kPa), wall mount.
MS-151-LCD	Differential pressure transmitter, 4-20 mA output, selectable range 25" w.c. (5 kPa), wall mount, with LCD.
