Name: Fluke 376 FC True-RMS Clamp Meter
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: 376 FC
Price: 152.00 USD
Availability: InStock

Home > products > Precision Pressure Sensor >

Fluke 376 FC True-RMS Clamp Meter

True-RMS Clamp Meter

Fluke Clamp Meter

Brand Name:

Fluke

Certification:

Model Number:

376 FC

Request A Quote

Product Details

Range:

2500 A

Resolution:

0.1 A

Accuracy:

3% ±5 Digits (5 – 500 Hz)

Highlight:

2500 A Range Clamp Meter, 0.1 A Resolution Clamp Meter

Highlight:

True-RMS Clamp Meter

Fluke Clamp Meter

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

Testo 330-2 LL Pro Flue Gas Analysis Kit Colour Graphic Display and 600 G Display Function

Get Best Price

Honeywell BW Solo Lite BWS2-S-Y Sulfur Dioxide (SO₂) Gas Detector

Get Best Price

Fluke 15B+ and 17B+ Digital Multimeters with Test Leads and Accessories

Get Best Price

Keyence AP-31A AP Series 12–24V DC Pressure Sensor / Pressure Switch

Get Best Price

86--17719566736

Contact Now

Product Description

Fluke 376 FC True-RMS Clamp Meter

Key Features

Attribute	Value
Range	2500 A
Resolution	0.1 A
Accuracy	3% ±5 Digits (5 – 500 Hz)
Highlight	2500 A Range Clamp Meter, 0.1 A Resolution Clamp Meter

Technical Specifications

AC Current via Jaw

Range	999.9 A
Resolution	0.1 A
Accuracy	2% ±5 digits (10 Hz to 100 Hz) 2.5% ±5 digits (100-500 Hz)
Crest Factor (50 Hz/60 Hz)	3 @ 500 A 2.5 @ 600 A Add 2% for C.F. >2

AC Current via Flexible Current Probe

Range	2500 A
Resolution	0.1 A (≤ 600 A) 1 A (≤ 2500 A)
Accuracy	3% ±5 digits (5 - 500 Hz)
Crest Factor (50/60Hz)	3.0 at 1100 A 2.5 at 1400 A 1.42 at 2500 A Add 2% for C.F. > 2

Flexible Current Probe Specifications

	i2500-10 Flex	i2500-18 Flex	i2500-36 Flex
Distance from Optimum	0.5 in (12.7 mm)	1.4 in (35.6 mm)	4.8 in (122.2 mm)
Error	±0.5 %	±0.5 %	±0.5 %

Measurement uncertainty assumes centralized primary conductor at optimum position, no external electrical or magnetic field, and within operating temperature range.

DC Current

Range	999.9 A
Resolution	0.1 A
Accuracy	2% ±5 digits

AC Voltage

Range	1000 V
Resolution	0.1 V (≤600.0 V) 1 V (≤1000 V)
Accuracy	1% ±5 digits (20 Hz to 500 Hz)

DC Voltage

Range	1000 V
Resolution	0.1 V (≤600.0 V) 1 V (≤1000 V)
Accuracy	1% ±5 digits

mV DC

Range	500.0 mV
Resolution	0.1 mV
Accuracy	1% ±5 digits

Frequency via Jaw

Range	5.0 Hz to 500.0 Hz
Resolution	0.1 Hz
Accuracy	0.5% ±5 digits
Trigger level	5 Hz to 10 Hz, ≥10 A 10 Hz to 100 Hz, ≥5 A 100 Hz to 500 Hz, ≥10 A

Frequency via Flexible Current Probe

Range	5.0 Hz to 500.0 Hz
Resolution	0.1 Hz
Accuracy	0.5% ±5 digits
Trigger level	5 Hz to 20 Hz, ≥25 A 20 Hz to 100 Hz, ≥20 A 100 Hz to 500 Hz, ≥25 A
