Name: VIPA 313-5BF23 Industrial PLC Controller with SPEED7 Technology
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: 313-5BF23
Price: 152.00 USD
Availability: InStock

Home > products > Precision Pressure Sensor >

VIPA 313-5BF23 Industrial PLC Controller with SPEED7 Technology

VIPA Industrial PLC Controller

313-5BF23 Industrial PLC Controller

SPEED7 Technology Industrial PLC Controller

Brand Name:

VIPA

Certification:

Model Number:

313-5BF23

Request A Quote

Product Details

Inrush Current:

11 A

Power Loss:

14 W

Rated Load Voltage:

DC 24 V

Rated Value:

DC 24 V

Input Voltage For Signal %220%22:

DC 0...5 V

Highlight:

313SC VIPA 313-5BF23 CPU, Industrial Grade VIPA 313-5BF23 CPU

Highlight:

VIPA Industrial PLC Controller

313-5BF23 Industrial PLC Controller

SPEED7 Technology Industrial PLC Controller

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

Testo 330-2 LL Pro Flue Gas Analysis Kit Colour Graphic Display and 600 G Display Function

Get Best Price

Honeywell BW Solo Lite BWS2-S-Y Sulfur Dioxide (SO₂) Gas Detector

Get Best Price

Fluke 15B+ and 17B+ Digital Multimeters with Test Leads and Accessories

Get Best Price

Keyence AP-31A AP Series 12–24V DC Pressure Sensor / Pressure Switch

Get Best Price

86--17719566736

Contact Now

Product Description

VIPA 313-5BF23 Industrial PLC Controller with SPEED7 Technology

Product Highlights

313SC VIPA 313-5BF23 CPU
Industrial Grade VIPA 313-5BF23 CPU

Attribute	Value
Inrush Current	11 A
Power Loss	14 W
Rated Load Voltage	DC 24 V
Rated Value	DC 24 V
Input Voltage For Signal "220"	DC 0...5 V

Product Description

The VIPA 313-5BF23 is a high-performance programmable logic controller (PLC) featuring SPEED7 technology for rapid processing and reliable industrial automation. Equipped with 24 digital inputs, 16 digital outputs, 5 analog inputs, and 2 analog outputs, this PLC offers versatile connectivity for the control of complex systems.

Key Features

High-Speed Processing

SPEED7 technology ensures fast scan times for real-time control in dynamic industrial environments.

Diverse I/O Configuration

24 digital inputs (24V DC) and 16 digital outputs (relay or transistor) for switching applications
5 analog inputs (voltage/current) and 2 analog outputs (0-10V/4-20mA) for precision measurement
Integrated Pt100 input for direct temperature sensor connection

Advanced Control Functions

3 high-speed counters (up to 100kHz) for encoder or pulse counting
3 PWM channels for stepper motor or speed control applications

Flexible Communication

RJ45 Ethernet port for PG/OP programming and industrial network integration
2x RS485 ports supporting protocols: MPI, Modbus RTU, USS (drive control), 3964(R), and ASCII

Expandable & Secure Design

Stackable up to 8 modules for scalable I/O expansion
Locking SD/MMC card slot for backup and transfer of programs/data

Programming Compatibility

Supports industry-standard software: WinPLC7, SIMATIC Manager, and TIA Portal for easy integration.
