Product Details:
Place of Origin: Shaanxi, China (Mainland)
Brand Name: KACISE
Model Number: DGP
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/Pieces
Price: Negotiable
Packaging Details: carton or customers requests available
Delivery Time: 5 working days after payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 Piece/Pieces per Month
Contact Now
Detailed Product Description
Pressure Range: 0~20MPa Overload: 150%
Accuracy: 0.5% Pressure Type: Gauge Pressure
Stability: ≤0.2%/year Power Supply: 12~32VDC
High Light:

stainless steel pressure gauge

,

submersible pressure sensor

High Accuracy Stainless Steel DPG Digital Pressure Gauge Operation Instruction




Description



DGP digital pressure gauge is wholly an electronic structure. It adopts high accuracy piezoresistive pressure sensor. After processed by high precision and low temperature drift amplifier, signal output by the sensor enters high accuracy A/D convertor and is converted into digital signal. Digital signal is next calculated and processed by microprocessor. And pressure value is finally indicated by LED display.



DGP intelligent digital pressure gauge is convenient for operation, easy to set, safe and reliable.



DPG Digital High Precision Pressure Gauge Interference Proof Design 0


Features



  • Complete intelligent 2 wires 4-20mA working mode, 4 digits 0.56”LED display.
  • LED highlighting display.
  • Imported ceramic capacitance pressure sensor core.
  • Zero position reset function, parameter batch changing function and panel key changing function to meet different users’ special need.
  • Complete digital calibration, no any movable potentiometer, low temperature drift.
  • Interference proof design. DPG digital pressure gauge can be normally used under bad electromagnetic circumstance.
  • Due to special interference proof design, DPG digital pressure gauge fits for applications of heat supply and frequency conversion constant pressure water supply.
  • Water proof outlet junction. Whole gauge protection grade IP65.



Technical Parameters



Measuring range 0~20MPa Accuracy 0.5%
Overload 150% Pressure Type Gauge Pressure
Stability ≤0.2%/year Power Supply 12~32VDC
Display LED Indicating Range -1999~9999
Ambient Temperature -20℃~70℃ Relative Humidity ≤90%
Installation Thread M20*1.5 Port Material Stainless Steel


Dimensions

DPG Digital High Precision Pressure Gauge Interference Proof Design 1



Operation



DPG Digital High Precision Pressure Gauge Interference Proof Design 2



  • Wiring

2 wires mode transmitter’s outlet is 2 wires

Red: 24DC+ Black:24-

  • Measurement and Calibration

Standard pressure should be provided when calibration.

  • While zero position standard pressure, long press ▼ key 5 seconds, zero position is calibrated.
  • While full scale standard pressure, long press ▲ key 5 seconds, full scale is calibrated.



Notice



  • Storage and suitable ambient temperature range: -20℃~70℃

relative humidity < 80%

  • When connected to piping, DGP digital pressure gauge should be concentric.



Warranty



Based on users’ abiding to operation and protection regulation, warranty period for 12 months since DGP digital pressure gauge is sent from Kacise.
