| Place of Origin: | CHINA |
| Brand Name: | Kacise |
| Certification: | CE |
| Model Number: | GXPS800H |
| Minimum Order Quantity: | 1Piece/pieces |
|---|---|
| Price: | nogotiable |
| Packaging Details: | each unit has individual box and all boxes are packed in standard packages or customers requests available |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000 piece/pieces per week |
| Pressure Range: | 0 ～ 150MPa…300MPa…400MPa…600MPa…800MPa…1000MPa…1200MPa…1500MPa | Accuracy: | ±0.25%FS、±0.5%FS；±1.0%FS Selectable |
|---|---|---|---|
| Overload Pressure: | 120%FS | Operating Temperature: | -40～+85°C/125°C/250°C Selectable |
| Output Signal: | 4~20mA 0～5VDC 0～10VDC 0~20mA | Power Supply: | 12～36VDC 12～36VDC 3~15Vdc |
| High Light: | piezoresistive pressure transmitter,explosion proof pressure transmitter |
||
Feature
Application
Electronic interface and signals definition
Parameter
| Spec. | Numerical value | ||
| Pressure range | 0 ～ 150MPa…300MPa…400MPa…600MPa…800MPa…1000MPa…1200MPa…1500MPa | ||
| Overload pressure | 120%FS | ||
| Secondary containment | 200%FS or 1700MPa, whichever is less | ||
| Accuracy | ±0.25%FS,±0.5%FS；±1.0%FS selectable | ||
| Stability | Typical range:≤±0.5%FS/year | ||
| Operating temperature | -40～+85°C/125°C/250°C selectable | ||
| Compensation temperature | -40～+80°C/120°C | ||
| transmitter | sensor | ||
| Electrical performance | 2 line | 3 line | 4 line |
| Output signal | 4~20mA |
0～5VDC 0～10VDC |
0~20mA |
| Power supply | 12～36VDC | 12～36VDC | 3~15Vdc |
| vibration/Impact | 5-1000Hz amplitude 2mm axes X/Y/Z 30s output dispersion less than 0.1%F.S. | ||
| Electrical connection |
DIN43650 Hirschmann connector(IP65) Air plug Fixed cable(IP67) |
||
| Pressure port | M20×1.5,M16×1.5,9/16-18UNF or customized | ||
Company Information
Xi'an Kacise is qualified with ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof certificates, etc. which ensure that our products comply with international standards.
We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. Based on experienced technical and management personnel, through efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.
Currently, Kacise sensors have already been exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regard “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.
