High Temperature Precision Pressure Sensor Full Stainless Steel Various Output Signal

High Temperature Precision Pressure Sensor Full Stainless Steel Various Output Signal

  • High Temperature Precision Pressure Sensor Full Stainless Steel Various Output Signal
  • High Temperature Precision Pressure Sensor Full Stainless Steel Various Output Signal
High Temperature Precision Pressure Sensor Full Stainless Steel Various Output Signal
Product Details:
Place of Origin: China
Brand Name: Kacise
Certification: Intrinsically safe, explosion proof, CE certificate
Model Number: GXT100
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece/pieces
Price: negotiable
Packaging Details: each unit has individual box and all boxes are packed in standard packages or customers requests available
Delivery Time: 3-5 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2000 Piece/Pieces per Week
Contact Now
Detailed Product Description
Measurement Range: -55~1200℃ Accuracy: ±0.5%(typical) ±1%(Max.)
Long Term Stability: ±1.0%F.S/year Power Supply: 15~30VDC
Output Signal: 4~20mA 0/1~5/10VDC Pressure Port: M27×2 Or Customize
Housing Material: -20°C~120°C Load Pressure: 1Cr18Ni9Ti Stainless Steel
Cable: Polyethylene
High Light:

high accuracy pressure sensor

,

piezoresistive pressure transmitter

Full stainless steel High Temperature Transmitter Various Output Signal



1,Application



☆ For the temperature measuring of the gas and liquid that can be compatible with 316L.
☆ Petroleum industry, chemical industry, metallurgy industry, electric power, hydrology etc.


2,Feature



☆ Wide measurement range, Full stainless steel
☆ Protection:IP65
☆ Various output signal.
☆ CE Certification
☆ ExiaIICT6.



3,Introduction



GXT100 temperature transmitter uses specialized temperature module, it can do the linearity correction for the most
kinds of thermocouple and thermal resistance, then output the standard analogue signal.
It has high reliability and stability..



4,Dimension



High Temperature Precision Pressure Sensor Full Stainless Steel Various Output Signal 0



5,Parameter



Measurement Range -55~1200℃
Accuracy ±0.5%(typical) ?1%(Max.)
Long term stability ±1.0%F.S/year
Power supply 15~30VDC
Output signal 4~20mA 0/1~5/10VDC
Pressure port M27×2 or customize
Housing material 1Cr18Ni9Ti stainless steel
Cable polyethylene
Protection IP65



6,Our service



High Temperature Transmitter can be customized by your special request, We can supply technical consulting service for your user.
The quality principle: Quality is the best sales
Payment: We accept T/T, PayPal, Western Union, MoneyGram , Escrow
Shipping:
1. All parts will be shipped out within 1 - 3 working days after confirm the payment
2. DHL / FEDEX / UPS / EMS / TNT / China Post /Aramex
3. We are not responsible for force majeure accidents, delays or other issues, like the shipping service.

After-sales service
We can offer good technical support and good warranty for you after service as professional manufacturer.

Warranty: One year
During the warranty, if the goods after delivery are damaged with error caused only by itself quality problem, the goods can be returned for free repair and maintenance. however, if the goods is damaged with error caused by user’ s man-made and force majeure factor, we will be not responsible for free repair and maintenance.
