chemical oxygen demand measurement & monitoring cod monitoring

Product Details

Product Name:

COD Sensor

Application:

COD Analysor

Digital Sensor:

RS-485

Testing:

SAC, COD,TOC

Port:

Xi'an Or Other

Payment & Shipping Terms

Price

$2,000.00 - $3,000.00/pieces

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Supply Ability

500 Piece/Pieces per Month

KCW101 Frequency - Modulated Electromagnetic Wave Water Treatment Equipment

Get Best Price

KHM100 On - line Automatic Heavy Metal Water Quality Monitor

Get Best Price

KCW104 Automatic Softening Water Device

Get Best Price

KCW105 Ionization Water Purification Device

Get Best Price

86--17719566736

Contact Now

Product Description

chemical oxygen demand measurement & monitoring cod monitoring

Introduction

The COD sensor is Kacise's new generation of environmentally friendly COD / TOC sensors. It does not require reagents, is non-polluting, is more economical, and is more environmentally friendly. The water volume is small, easy to install, and water quality monitoring can be performed online. Automatically compensates for turbidity disturbances and is equipped with an automatic cleaning device that maintains excellent stability even over long periods of time.

Principle

Many organic substances dissolved in water absorb ultraviolet light. Therefore, by measuring the

absorption of these organic substances by ultraviolet light at a wavelength of 254 nm, the total amount of

organic pollutants in water can be measured. The Kacise COD series sensor uses two light sources, one

254nm ultraviolet light and one 850nm infrared light, which can automatically compensate the optical

path attenuation and turbidity effects, thus achieving more stable and reliable measurement values.

Features

Digital sensor, RS-485 output, support MODBUS

No reagents, no pollution, more economical, more environmentally friendly

Can measure SAC, COD, TOC and other parameters

Automatically compensates for turbidity interference for outstanding test performance

Technical Specifications

Product	Measuring range	Application field
KWS100A (40mm gap)	SAC 0.1 to 50 1/m COD 0.15 to 75 mg/l equiv. KHP TOC 0.06 to 30 mg/l equiv KHP	Tap water treatment
KWS100B (8mm gap)	SAC 0.5 to 250 1/m COD 0.75 to 370 mg/l equiv. KHP TOC 0.3 to 150 mg/l equiv KHP	Sewage treatment plant outlet, natural waters
KWS100C (2mm gap)	SAC 1.5 to 700 1/m COD 2.5 to 1000 mg/l equiv. KHP TOC 0.9 to 410 mg/l equiv KHP	Industrial process control

chemical oxygen demand measurement & monitoring cod monitoring 0

chemical oxygen demand measurement & monitoring cod monitoring 1
