Place of Origin:
Shaanxi, China
Brand Name:
Kacise
Certification:
CE
Model Number:
KWS-1000
Video
Video
The Kacise online water sensor employs the principle of fluorescence. When contrasted with several frequently utilized methods, the fluorescence method stands out as being significantly more efficient and swifter. Not only that, it offers the capability of being monitored online in real time, providing continuous and up-to-the-minute data. The sensor demonstrates superior repeatability and stability, ensuring consistent and reliable performance over an extended period. Optionally accompanied by an automatic cleaning brush, it effectively eliminates air bubbles that might otherwise interfere with accurate measurements. Additionally, it reduces the adverse effects of contamination on the measurement process, thereby prolonging the maintenance cycle. This enables the sensor to maintain excellent stability for long-term online use, functioning reliably without frequent disruptions or the need for excessive maintenance. Crucially, it can play a vital early warning role when it comes to oil pollution in water. It promptly detects the slightest presence of oil contaminants, allowing for prompt and appropriate remedial actions to be taken before the pollution escalates and causes significant damage to the aquatic environment.
| Model | KWS-1000 |
| Measuring Range | 0-50ppm or 0-0.40FLU |
| Principle | fluorescence method |
| Resolution | 0.01ppm |
| Accuracy | ±3%F.S |
| The detection limit | According to actual oil sample |
| Linearity | R2>0.999 |
| IP Grade | IP68 |
| Max. depth | 10m under water |
| Temperature Range | 0~50℃ |
| Output | RS485, Modbus |
| Installation | Submersible |
| Dimension | Φ45*175.8mm |
| Power Supply | DC5-12V, current<50mA (when not cleaning) |
| Cable Length | Standard 10m, customizable |
| Casing Material | 316L (titanium alloy customizable) |
| Self-cleaning Function | Optional |
