KWS-200 On-line Ammonia Nitrogen Sensor For Continuous Monitoring Of Ammonia Nitrogen In Wastewater

KWS-200 On-line Ammonia Nitrogen Sensor For Continuous Monitoring Of Ammonia Nitrogen In Wastewater

KWS-200 Ammonia Nitrogen Sensor

Wastewater Ammonia Nitrogen Sensor

Continuous Monitoring Ammonia Nitrogen Sensor

Place of Origin:

china

Brand Name:

KACISE

Certification:

CE

Model Number:

KWS-201

Contact Us
Request A Quote
Product Details
Measuring Range:
0-100mg/L (optional 0-1000mg/L)
Measurement Accuracy:
±10% Or ±0.5mg/L (whichever Is Greater)
Protection Level:
IP68
Sensor Interface:
Support RS-485, MODBUS Protocol
Casing:
POM+316L (customizable Titanium Alloy)
Highlight:

KWS-200 Ammonia Nitrogen Sensor

,

Wastewater Ammonia Nitrogen Sensor

,

Continuous Monitoring Ammonia Nitrogen Sensor

Payment & Shipping Terms
Minimum Order Quantity
1PCS
Packaging Details
each unit has individual box and all boxes are packed in standard packages or customers requests available
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
1000 Piece/Pieces per Week negotiable
Product Description

Product Description

The KWS-200 on-line ammonia nitrogen sensor is an essential device for wastewater management. Specifically designed to continuously monitor ammonia nitrogen in wastewater, it offers high-precision detection. Its advanced technology enables it to accurately measure varying ammonia nitrogen levels, providing real-time data that is crucial for efficient treatment processes. With a durable build, it can withstand the harsh and corrosive environment of wastewater. This sensor's reliable performance ensures uninterrupted monitoring, allowing operators to promptly adjust treatment parameters based on the ammonia nitrogen concentration. It significantly contributes to optimizing wastewater treatment, reducing environmental impact, and meeting regulatory compliance standards.
Feature

  • Digital sensor, RS-485 output, supports MODBUS;
  • Automatically compensate for pH and temperature in water;
  • Ion electrode method, no electrolyte required, electrodes can be replaced separately, easy to maintain.
  • No reagents required, no pollution, more economical and environmentally friendly;

Parameter

Name Ammonia Nitrogen sensor
Measuring range 0-100mg/L (optional 0-1000mg/L)
Measurement accuracy ±10% or ±0.5mg/L (whichever is greater)
Resolution 0.01mg/L
pH range 4-10pH
pH accuracy ±0.1pH
pH resolution 0.01
Sensor size φ36mm*265rmm (with protective cover)
Protection level IP68
Maximum depth 10 meters underwater
Temperature range 0-50℃
Sensor interface Support RS-485, MODBUS protocol
Assembly NPT3/4 thread, immersion installation
Power consumption 0.25W (recommended power supply: DC 9-24V, ≥1A)
Probe cable length 10 meters (default), customizable
Calibration 1-point or 2-point calibration
Casing POM+316L (customizable titanium alloy)
Dimension
KWS-200 On-line Ammonia Nitrogen Sensor For Continuous Monitoring Of Ammonia Nitrogen In Wastewater 0
Cases
KWS-200 On-line Ammonia Nitrogen Sensor For Continuous Monitoring Of Ammonia Nitrogen In Wastewater 1
