0-2MPa Pressure Range Ceramic Capacitive Pressure Sensor for Gas and Liquid in Industrial Applications

KAW102 Industrial Pressure Sensor for Gas and Liquid

Product Introduction

The KAW102 Industrial Pressure Sensor for Gas and Liquid is a reliable solution for industrial pressure measurement tasks. It is applicable to measure the pressure of liquids, gases, and steam, making it a valuable asset in various industrial processes.

Equipped with a ceramic capacitive pressure sensor, this device can measure pressures within the ranges of 0 - 1MPa and 0 - 2MPa, covering gauge pressure and sealing pressure. The 0.5 - 4.5V output signal and 4.75 - 5.25 VDC power supply enable seamless integration into industrial systems. Its robust design allows it to function effectively in a wide temperature environment, from -40℃ to 110℃ for both ambient and working conditions, with a defined compensation temperature range of -20℃ to 70℃.

Features

• Media Adaptability: Applicable to liquids, gases, and steam, suitable for multiple industrial applications.
• Pressure Range: Pressure measurement ranges of 0 - 1MPa and 0 - 2MPa to meet diverse industrial pressure requirements.
• Sensing Precision: Achieves an accuracy of 1%F.S. due to the ceramic capacitive pressure sensor, ensuring reliable pressure readings.
• Output Signal: Outputs a 0.5 - 4.5V signal, facilitating data transmission to other equipment.
• Power Supply: Operates stably with a 4.75 - 5.25 VDC power supply.
• Temperature Drift Control: Has a controlled temperature drift of ±0.15% F.S. for zero and full range within the -20℃ to 70℃ compensation temperature range.
• Temperature Tolerance: Can withstand ambient and working temperatures from -40℃ to 110℃.
• Connection Options: Offers flexible electrical connection methods (Cable Outlet and Parkard Connector) and mechanical connections (G1/4 and NPT 1/4 Male) for convenient installation.
• Brass Housing: Features a brass housing, providing good durability and resistance in industrial settings.
