| Place of Origin: | China (Mainland) |
| Brand Name: | Kacise |
| Certification: | certificate of explosion-proof, CE |
| Model Number: | KS3ARG02D |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Packaging Details: | each unit has individual box and all boxes are packed in standard packages or customers requests available |
| Delivery Time: | 5-8 working days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 Pieces per Week |
| Nonlinearity: | ≤0.05(%FR) | Weight: | ≤60100(g) |
|---|---|---|---|
| Zero-bias: | ≤±0.1(In 500°/s)(deg/s) | Vibration: | 6.06(g @ 20~2000 Hz) |
| Operating Temperature: | -40~+80(°C) | Data Updating Rate(can Set): | 2000(Hz@460800) |
| Zero-bias Repeatability: | ≤0.05(deg/s) | Shock: | 5000(g , 0.1 Ms, 1/2 Sine) |
| High Light: | 0.1 Ms Response Time Gyroscope Sensor,Industrial Grade MEMS Gyroscope Sensor |
||
The KS3ARG02D series represents a cutting-edge solid state angular rate sensor, commonly referred to as a gyro, that is specifically engineered to measure angular velocity with exceptional accuracy. At the core of this device is the groundbreaking utilization of micromechanical electronic system (MEMS) technology, providing a sophisticated and compact sensing solution.
This gyro leverages chips crafted through the use of bipolar metal oxide semiconductor (BIMOS) technology alongside a unique production process. The manufacturing excellence is further exemplified by the spherical grid layout used in the current carrier welding process, underscoring the meticulous attention to detail in the sensor's design.
Reliability and durability are cornerstones of the KS3ARG02D series. The rugged packaging is designed to provide high levels of dependability even under harsh conditions. Adding to its robust nature is the presence of a built-in Self-Test function that permits Built-In Testing (BIT) to facilitate onboard diagnostic capabilities.
The sensor comes equipped with an array of advanced features including zero bias calibration and temperature drift compensation. These features ensure reliable performance over a broad measurement range and wide operating bandwidth. Non-linear corrections are also applied to maintain accuracy. Furthermore, the KS3ARG02D sensor is constructed to perform within a vast temperature scope, showcasing its versatility in various environments.
Despite its array of functionalities, the sensor maintains a discreet profile that is both small in size and light in weight, making it an ideal component for applications where space and weight are at a premium. Its resistance to high-impact acceleration assures sustained performance even when subjected to intense mechanical shocks or vibrations.
Dimensions
| Performance parameter | KS3ARG02D | |
| gyro |
range (deg/s) |
±500(triaxial) |
| Zero-bias(deg/s) | ≤±0.1(In 500°/s) | |
| Zero-bias stability(deg/h) | ≤0.5allan deviation | |
| Zero-bias repeatability(deg/s) | ≤0.05 | |
| nonlinearity(%FR) | ≤0.05 | |
| Random walk(°/√h) | 0.15 | |
| Mean time between failures(Kh MTBF) | 10 | |
| Interface characteristic | power(V) | DC5 |
| power dissipation(W @5V DC) | ≤1 | |
| electrical interface | RS422 | |
| data updating rate(can set) | 2000(Hz@460800) | |
| operating environment | operating temperature(°C) | -40~+80 |
| storage temperature(°C) | -55~+85 | |
| Vibration(g @ 20~2000 Hz) | 6.06 | |
| Shock(g , 0.1 ms, 1/2 Sine) | 5000 | |
| physical property | Size(mm) | 45×39×20 |
| Weight(g) | ≤60 | |
The Kacise KS3ARG02D electronic gyroscope sensor, originating from the China Mainland, is a high-precision inertial measurement component that offers a wide measurement range and high impact acceleration resistance, making it suitable for a variety of applications and scenarios. With its explosion-proof certification and CE marking, this sensor meets rigorous safety and quality standards, assuring its reliability in demanding environments.
The KS3ARG02D model is designed for versatile use cases where accurate angular rate detection is critical. This includes but is not limited to, robotics, where precise movement control is necessary, and automotive systems, where stability and navigation are enhanced by the sensor's capabilities. The wide measurement range allows for deployment in systems that experience vast ranges of motion, while the high impact acceleration resistance ensures the sensor's performance remains unaffected in high-vibration contexts such as heavy machinery monitoring or aerospace testing.
With a robust operating temperature range of -40 to +80 degrees Celsius, the KS3ARG02D can function reliably in extreme conditions, making it an ideal choice for outdoor applications including maritime navigation systems, geological survey equipment, and remote monitoring stations that endure harsh weather conditions.
The compact size of 45×39×20 mm and a power requirement of just DC5V make the Kacise gyroscope sensor a convenient addition to systems where space is at a premium and energy efficiency is desired. The RS422 electrical interface allows for straightforward integration with existing electronic systems, enhancing the sensor's applicability to a broad spectrum of industrial and technological uses.
Customers can place a minimum order quantity of just 1 piece, with each unit arriving in an individual box. All boxes are securely packed in standard packages, with the option to accommodate customer requests. Kacise ensures a swift delivery time of 5-8 working days, backed by a supply ability of 1000 pieces per week, catering to projects of various scales with efficiency and speed. Payment is made convenient through T/T, Western Union, or MoneyGram.
In summary, the Kacise KS3ARG02D electronic gyroscope sensor is a versatile and durable component suited for applications ranging from advanced robotics and automotive systems to heavy-duty industrial machinery and harsh environmental monitoring. Its certification, robust build, and user-friendly interfacing combine to make it a reliable and essential part of modern measurement and control systems.
Welcome to the Product Technical Support and Services page for the Electronic Gyroscope Sensor. Our dedicated team is committed to providing you with the highest quality support to ensure your device functions at its best. We offer a wide range of services to help you get the most out of your sensor, including:
User Manuals and Documentation: Access comprehensive user manuals, data sheets, and detailed product documentation to understand your sensor's capabilities fully and optimize its use.
FAQs and Knowledge Base: Our extensive FAQs and knowledge base contain answers to common questions and provide valuable information to troubleshoot issues quickly and independently.
Our commitment to excellence ensures that you receive the support you need when you need it. For any further assistance, please refer to our contact page for ways to get in touch with our support team.
The Electronic Gyroscope Sensor is enclosed in a static-free, vacuum-sealed package to ensure protection from electrostatic discharge and environmental factors. The sensor is cushioned within high-density foam, molded to its unique shape for a snug fit, reducing the risk of movement and impact during transportation.
The primary packaging is then placed inside a durable, corrugated cardboard box that is designed to withstand the rigors of shipping. The box is clearly marked with fragile handling symbols and includes a comprehensive list of handling instructions to ensure the product is transported with the utmost care.
Prior to shipment, the package is sealed with tamper-evident tape and the box is weighed to confirm the presence of all components. A tracking label with a unique barcode is affixed to the outside of the box, allowing for easy tracking and confirmation of delivery.
We ship our Electronic Gyroscope Sensor through trusted courier services, offering expedited shipping options for timely and reliable delivery to our customers. Upon dispatch, an email with the tracking details is sent to the customer, providing transparency and peace of mind throughout the shipping process.
