CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA

CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA

electronic tilt sensor

tilt measurement sensor

Place of Origin:

Shaanxi, China (Mainland)

Brand Name:

KACISE

Certification:

CE

Model Number:

K-IMU-1000

Contact Us
Request A Quote
CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA
Product Details
Input Voltage:
9~36 VDC
Input Current:
≤70mA
Output Mode:
CAN
Baud Rate:
Optional
Output Data Rate:
200Hz(default)
Output Data Format:
CANOPEN
Highlight:

electronic tilt sensor

,

tilt measurement sensor

Payment & Shipping Terms
Minimum Order Quantity
1 Piece/Pieces
Price
Negotiable
Packaging Details
carton or customers requests available
Delivery Time
5 working days after payment
Payment Terms
L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability
1000 Piece/Pieces per Week negotiable
RELATED PRODUCTS
Good price Platform Erection Precision Tilt Sensor , Analog Tilt Sensor 5Hz Bandwidth online

Platform Erection Precision Tilt Sensor , Analog Tilt Sensor 5Hz Bandwidth

Get Best Price
Good price CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA online

CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA

Get Best Price
Good price Zigbee Wireless Inclinometer Sensor Battery Powered Dip Angle Measuring System online

Zigbee Wireless Inclinometer Sensor Battery Powered Dip Angle Measuring System

Get Best Price
Good price Low-power analog output tilt sensors for construction machinery Precision tilt sensors with bandwidth 5Hz online

Low-power analog output tilt sensors for construction machinery Precision tilt sensors with bandwidth 5Hz

Get Best Price
Contact Us
86--17719566736
Contact Now
Product Description

CAN Bus Output Inertial Measurement Unit For Power Conductor Galloping Monitoring System

Features

☆CAN bus output
☆Whole temperature range compensation
☆Nonlinear correction, Cross coupling correction
☆impact resistance, vibration performance
☆correspond CANOPEN protocol

Dimension

CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA 0

Application fields

☆ Power conductor galloping monitoring system


S  Specification



Type K-IMU-1000
Electric character
Input voltage 9~36 VDC
Input current ≤70mA
Output Mode CAN
Baud Rate Optional
Output Data Rate 200Hz(default)
Output Data format CANOPEN
Performance index
Sensor Gyroscope   accelerometer
Range ±50 °/s   ±2g
Bandwidth     ≥40 Hz
Accuracy ≤ 0.1°/s   0.001g
Nonlinear (%FS)   ≤ 0.1°/F.S.
Start-up time (ms) ≤ 1 s
Environmental characteristics
Temperature (°C) -40℃~+70℃ -55℃~+70℃
Storage Temperature -55℃~+100℃
Resistant to shock 3000g
Physical Characteristics
Weight (g) 250 g
Dimensions 64×45×35mm

CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA 1Dimensions

CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA 2CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA 3

workshop​


CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA 4

CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA 5

CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA 6



Application

CAN Bus Output Inertial Motion Unit For Power Conductor Galloping Monitoring System with input current ≤70mA 7
