Industrial Digital Water Quality Sensor RS-485 Output Sewage Treatment

Industrial Digital Water Quality Sensor RS-485 Output Sewage Treatment

  • Industrial Digital Water Quality Sensor RS-485 Output Sewage Treatment
  • Industrial Digital Water Quality Sensor RS-485 Output Sewage Treatment
  • Industrial Digital Water Quality Sensor RS-485 Output Sewage Treatment
  • Industrial Digital Water Quality Sensor RS-485 Output Sewage Treatment
Industrial Digital Water Quality Sensor RS-485 Output Sewage Treatment
Product Details:
Place of Origin: Shaanxi, China (Mainland)
Brand Name: KACISE
Certification: CE,ISO
Model Number: KBU601
Payment & Shipping Terms:
Minimum Order Quantity: 0-100
Price: Negotiable
Packaging Details: carton or customers requests available
Delivery Time: 5 working days after payment
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100
Contact Now
Detailed Product Description
Measuring Range: 0-500ppb Or 0-5000ppb Resolution: 0.1ppb
Accurate: 5% Protection Level: IP68
Product Material: POM Temperature Range: 0 ~ 50℃
High Light:

water turbidity sensor

,

oil in water sensor

Online oil-in-water sensor



Feature



Digital sensor, RS-485 output, support MODBUS. Optional automatic cleaning brush to eliminate the impact of oil on the measurement, this product uses a unique optical and electronic filtering technology to eliminate the impact of ambient light on the measurement, not affected by suspended solids.



Applications



The oil sensor in the water uses the principle of ultraviolet fluorescence analysis and has high sensitivity for detecting soluble and emulsifiable oil. were able Use a self-cleaning brush to effectively eliminate the effect of oil on the measurement. Suitable for oil field monitoring, industrial circulating water, condensed water, wastewater treatment,

Various water quality monitoring programs, such as surface water stations.



Technical Specifications



product oil-in-water sensor Self-cleaning oil-in-water sensor
principle Ultraviolet fluorescence method
Measuring range 0-500ppb or 0-5000ppb
Resolution 0.1ppb
accurate 5%
Protection level IP68
Deepest depth Underwater 60 meters underwater 10 meters
temperature range 0 ~ 50℃
Output Support RS-485, MODBUS protocol
Power supply DC 5~12V, current <50mA DC 5~12V, current <50mA (when not cleaned)
size Φ22mm*120mm Φ33mm*156mm
Probe cable length 10 m, customizable 5 m, 15 m and 30 m cable
product material POM
Self-cleaning system exist No
Optical window optical fiber
