Self Clean Bluetooth Fluorescence Dissolved Oxygen Meter Modbus Protocol

Self Clean Bluetooth Fluorescence Dissolved Oxygen Meter Modbus Protocol

    • Self Clean Bluetooth Fluorescence Dissolved Oxygen Meter Modbus Protocol
    • Self Clean Bluetooth Fluorescence Dissolved Oxygen Meter Modbus Protocol
    • Self Clean Bluetooth Fluorescence Dissolved Oxygen Meter Modbus Protocol
  • Self Clean Bluetooth Fluorescence Dissolved Oxygen Meter Modbus Protocol

    Product Details:

    Place of Origin: Shaanxi, China (Mainland)
    Brand Name: KACISE
    Certification: CE,ISO
    Model Number: KBU601

    Payment & Shipping Terms:

    Minimum Order Quantity: 0-100
    Price: Negotiable
    Packaging Details: carton or customers requests available
    Delivery Time: 5 working days after payment
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 100
    Contact Now
    Detailed Product Description
    Output: Support RS-485, MODBUS Protocol Measuring Range: 0~20mg/L
    Response Time: 10 Sec Temperature Range: 80 ~ 50℃
    Protection Level: IP6 Accurate: 1%
    Material: POM Or Ss316 Size: Φ16*180 Mm
    High Light:

    water turbidity sensor

    ,

    oil in water sensor

    Modbus Protocol Self Clean Bluetooth Supported Online Fluorescence Dissolved Oxygen Meter





    *.Description



    The Fluorescence Dissolved Oxygen Meter uses the world's leading fluorescence lifetime technology. Including a self-developed, internationally leading fluorescent dissolved oxygen sensor and a smart meter (Smart Meter) originally created by Hatoyama. It can quickly and accurately measure the dissolved oxygen content, with automatic compensation of water temperature and atmospheric pressure. At the same time, it can also be connected with smartphones and tablets via Bluetooth, and controlled by mobile phone or tablet with the support of Smart Meter app. Achieve many features that traditional instruments cannot.



    *.Feature



    Digital sensor, RS485 output, support MODBUS, no membrane, no electrolyte, no interference, no need for frequent calibration, no oxygen, no flow restriction, built-in temperature sensor, automatic temperature compensation.



    *.Technical Specifications



    product

    Portable Optical Dissolved Oxygen Sensor



    principle Ultraviolet fluorescence method
    Measuring range 0~20mg/L
    Response time 10 sec
    accurate 1%
    Protection level IP68
    Deepest depth Underwater 60 meters underwater 10 meters
    temperature range 0 ~ 50℃
    Output Support RS-485, MODBUS protocol
    Power supply DC 5~12V, current <50mA
    size Φ16*180 mm
    Probe cable length 5m, customizable 5 m, 15 m and 30 m cable
    Fluorescent cap life 1 year
    Maximum working pressure 6bar
    product material POM or ss316








    Self Clean Bluetooth Fluorescence Dissolved Oxygen Meter Modbus Protocol 0
