Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission

Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission

  • Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission
  • Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission
  • Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission
  • Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission
  • Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission
Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission
Product Details:
Place of Origin: china
Brand Name: Kacise
Certification: ce
Model Number: KBU601
Payment & Shipping Terms:
Minimum Order Quantity: 0-100
Price: Negotiable
Packaging Details: carton or customers requests available
Delivery Time: 10 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100
Contact Now
Detailed Product Description
Measuring Range: 0~400ug/L Resolution: 0.1 µg/L
Accurate: 1% Output: Support RS-485, MODBUS Protocol
Power Supply: DC 5~12V, Current <50mA Probe Cable Length: 10 M, Customizable 5 M, 15 M And 30 M Cable
High Light:

water turbidity sensor

,

oil in water sensor

Kws-400 Online Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission



1. Applications



The fiber chlorophyll sensor uses the principle of fluorescence to illuminate the water body through a high-energy LED light source according to the spectral absorption characteristics of chlorophyll a, to stimulate the water body chlorophyll a to generate fluorescence at a specific wavelength and measure the concentration of chlorophyll a in the water. The sensor fiber structure has excellent repeatability and stability and is not susceptible to ambient light. Eliminate air bubbles with an automatic cleaning brush and reduce the impact of contamination on the measurement, long-term online use, longer maintenance intervals and better stability



2. Feature



Digital sensor, RS-485 output, support MODBUS

With automatic cleaning brush to prevent contamination and eliminate air bubbles

Direct measurement is easier than traditional analysis methods

Continuous online monitoring and real-time control of water quality



Intelligent Water Quality Sensor Fiber Optic Chlorophyll Sensor RS485 Transmission 0

Integrated sensor field application example



3.Technical Specifications



product

Online Fiber optic chlorophyll sensor



principle Ultraviolet fluorescence method
Measuring range 0~400ug/L
Resolution 0.1 µg/L
accurate 1%
Protection level IP68
Deepest depth Underwater 60 meters underwater 10 meters
temperature range 0 ~ 50℃
Output Support RS-485, MODBUS protocol
Power supply DC 5~12V, current <50mA
size Φ22mm*120mm Φ33mm*156mm
Probe cable length 10 m, customizable 5 m, 15 m and 30 m cable
product material POM
Self-cleaning system exist No
Optical window optical fiber
