Name: Radial Installation Water Quality Sensor With 4.2V Rechargeable Lithium Battery
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KBU601
Price: 5,000.00 USD
Availability: InStock

Home > products > Water Quality Sensor >

Radial Installation Water Quality Sensor With 4.2V Rechargeable Lithium Battery

water turbidity sensor

oil in water sensor

Place of Origin:

china

Brand Name:

Kacise

Certification:

certificate of explosion-proof, CE

Model Number:

KBU601

Request A Quote

Radial Installation Water Quality Sensor With 4.2V Rechargeable Lithium Battery

Product Details

Power Supply:

4.2V Rechargeable Lithium Battery

Precision Grade::

0.5%FS，0.4%FS ，0.2%FS，0.1%FS，0.05%FS

Pressure Range::

-100kPa～0～600kPa～250MPa

Display::

SFTN Liquid Crystal Display，White Backlight，5 Digit Display.

Installation Method::

Radial Installation、axial Belt Mounting Plate、Split Type Installation

Storage Temperature::

（-30～80）℃

Highlight:

water turbidity sensor

oil in water sensor

Payment & Shipping Terms

Minimum Order Quantity

0-100

Price

Negotiable

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100

KCW101 Frequency - Modulated Electromagnetic Wave Water Treatment Equipment

Get Best Price

KHM100 On - line Automatic Heavy Metal Water Quality Monitor

Get Best Price

KCW104 Automatic Softening Water Device

Get Best Price

KCW105 Ionization Water Purification Device

Get Best Price

86--17719566736

Contact Now

Product Description

Oil, gas and water pressure monitoring Storage Manometer Pressure Gauge Easy Data Collect By USB

Specification

Item	Spec.
Pressure range	-100kpa~250pa~5kpa~250Mpa
Accuracy	0.5%, 0.4%, 0.2%, 0.1%, 0.05%, 0.02%
Display	5-digit dynamic display + percentage indicator
Pressure unit	Pa, kPa, MPa, psi, bar, mbar, mmH2O, mmHg, inH2O, inHg, kgf/cm2
Overload pressure	150% FS
Destruction pressure	200% FS
Power supply	4.2V rechargeable lithium battery
Temperature	-20 ℃ ~ 60 ℃
Humidity	≤ 85% RH
Calibration environment	20 ℃ ± 2 ℃
Explosion-proof level	ExiaIICT4 optional
IP Grade	IP66
Data record limit	11000 (50000 Selective)
Process connection	M20 × 1.5 (male), special thread customizable
Dimensions	height 170mm, width 110mm, thickness 50mm

Description

KPG201 precision digital pressure gauge is in accordance with the latest national standards developed and produced high-precision smart pressure measuring instruments. Pressure gauge mainly by the pressure sensor and signal processing circuit. Imported pressure sensor, superior performance, with high precision, corrosion resistance, shock resistance, vibration resistance, low temperature drift, high stability and other advantages; signal processing circuit using the latest ultra-low power processors, signal processing chips and power supply Management chip composition. High-capacity high-performance lithium battery-powered, no external power supply. The appearance of the instrument delicate, compact, beautiful, easy to use.

Features

• Wide temperature compensation, ultra-low power consumption.

• Unit changing, peak valley and other functions fully preserved.

• Multi additional setting and functions available, user can set by environment and habits.

• IP grade ≧ IP66, higher than the industry level.

Precision Grade:	0.5%FS,0.4%FS ,0.2%FS,0.1%FS,0.05%FS	Pressure Range:	-100kPa～0～600kPa～250MPa
Ambient Temperature:	(-20～50)℃	Relative Humidity:	＜95%
Atmospheric Pressure:	(86～106)kPa	Storage Temperature:	(-30～80)℃
Display:	SFTN Liquid Crystal Display,White Backlight,5 Digit Display.	Power Supply Mode:	4.2V Rechargeable Lithium Battery
Installation Method:	Radial Installation,axial Belt Mounting Plate,Split Type Installation

Storage Manometer Precision Digital Pressure Gauge Radial Installation
