| Place of Origin: | CHINA |
| Brand Name: | kacise |
| Certification: | CE |
| Model Number: | TVP600 |
| Minimum Order Quantity: | 0-100 |
|---|---|
| Price: | $0-$9000 |
| Packaging Details: | Common package or custom package |
| Delivery Time: | 3-10days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 100 |
| Monitoring Factor: | Volatile Phenol | Method: | 4-aminoantipyrine Spectrophotometer |
|---|---|---|---|
| Range: | (0.05-80) Mg/L Expandable | Measurement Mode: | Manual Measurement, Continuous Measurement, Periodic Measurement, Fixed-point Measurement, Automatic Calibration Measurement, Standard Solution Verification |
| Measurement Period: | 30 Minutes To 24 Hours, With Adjustable Expansion | Zero Drift: | ± 5% F. S |
| Range Drift: | ± 5% F. S | Repeatability: | ≤5% |
| High Light: | Volatile Phenol Water Quality Analyzer,RS485 Interface Water Quality Analyzer,4-aminoantipyrine Water Quality Testing Equipment |
||
Technical Parameters of Volatile Phenol Analyzer
| Model | TVP600 |
| Monitoring Factor | Volatile phenol |
| Method | 4-aminoantipyrine Spectrophotometer |
| Range | (0.05-80) mg/L expandable |
| Measurement Mode | Manual measurement, continuous measurement, periodic measurement, fixed-point measurement, automatic calibration measurement, standard solution verification |
| Measurement Period | 30 minutes to 24 hours, with adjustable expansion |
| Zero Drift | ± 5% F. S |
| Range Drift | ± 5% F. S |
| Repeatability | ≤5% |
| Accuracy | ± 5% |
| MBTF | > 720 hours |
| Stored data | Five years of data storage |
| Communication interface | 4-20mA, RS232, RS485, dry contact |
| Contour Dimension | 505 * 395 * 671(mm) |
Volatile phenol is an extremely toxic substance, and even a small amount consumed by humans can lead to acute poisoning symptoms. Persistent intake of water contaminated with phenol can result in various health issues, including headaches, rashes, itching, anemia, and neurological symptoms. Fish meat develops an unusual smell when the phenol content in water ranges from 0.1 to 0.2 mg/l, and at levels exceeding 5 mg/l, fish can die from poisoning.
The principle of measurement involves a reaction in an alkaline medium, where phenolic compounds in water, in the presence of potassium ferricyanide, react with 4-aminoantipyrine to form orange-red compounds. The absorbance of these compounds is proportional to the volatile phenol content in water, and the concentration is determined by measuring the absorbance.
This analyzer is suitable for both laboratory and industrial settings, enabling the testing of water quality in various environments such as industrial production processes, sewage, urban domestic wastewater, and surface waters like rivers, lakes, and seas.
Warranty and maintain services
The warranty period of the purchased products shall be governed by the sales contract.
Consumables: disposable consumables or perishable materials that need to be replaced after each use. Consumables have no warranty.
During the warranty period, all products can enjoy free after-sale service. However, please note that even if the products need to be repaired due to the following reasons during the warranty period, the Kacise company will implement a fee-based maintainservice. You will have to pay for the maintainfee and accessories fee:
Man-made damage;
Improper use;
The voltage of the power network exceeds the prescribed range of the products;
An irresistible natural disaster;
Replacement or use of parts, accessories, consumables not approved by the water company or repair by personnel not authorized by the Water Company;
Other faults not caused by the product itself.
After the expiration of the warranty period, the company can continue to provide fee-based maintainservices.
If you do not pay or delay to pay the fee for maintainservices, the company will temporarily suspend maintainservices until you pay.
