Place of Origin: | CHINA |
Brand Name: | kacise |
Certification: | CE |
Model Number: | KAN310 |
Minimum Order Quantity: | 0-100 |
---|---|
Price: | $0-$500 |
Packaging Details: | Common package or custom package |
Delivery Time: | 3-10days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 100 |
Range: | 0 ~ 10.00 Mg/L (0 ~ 100.00 Mg/L) | Resolution: | 0.01 Mg/L |
---|---|---|---|
Precision: | ± 10% Or ± 1mg/L | Operating Temperature: | 0 ~ 40 °C |
Working Pressure: | < 0.1 Mpa | The Ph Range Of The Medium: | 4 ~ 10ph |
High Light: | DCS Connect Nitrogen Sensor Water,PVC Membrane Nitrogen Sensor Water |
KAN310 integrated on-line ammonia-nitrogen sensor is made of ammonium ion selective electrode based on PVC membrane, which is used to measure the content of ammonium ion in water with temperature compensation.
Model Number | KAN310 |
Range | 0 ~ 10.00 mg/L (0 ~ 100.00 mg/L) |
Resolution | 0.01 MGL |
Precision | ± 10% or ± 1MG/L |
Operating Temperature | 0 ~ 40 °C |
Working Pressure | < 0.1 mpa |
The Ph Range Of The Medium | 4 ~ 10ph |
Temperature Compensation | Automatic temperature compensation (PT1000) |
Power Supply | 12 ~ 24 VDC ± 10% |
Signal Output | RS-485 bus, Modbus/RTU protocol |
Contact Material | PVC and POM |
Installation Mode | Immersion mounting |
Cable Length | 5 meters, other length can be customized |
Calibration Mode | Two-point calibration |
Power Consumption | < 0.05 W |
Protection Level | IP68 |
Tip: Do you know these methods for determining ammonia nitrogen?
Nessler's reagent spectrophotometry:
The alkaline solution of mercury iodide and potassium iodide reacts with ammonia to form a reddish-brown colloidal compound whose color is proportional to the content of ammonia nitrogen. The absorbance can usually be measured in the wavelength range of 410~425nm to calculate its content.
The lowest detectable concentration of this method is 0.025mg/L (photometric method), and the upper limit of determination is 2mg/L. Using visual colorimetry, the lowest detectable concentration is 0.02mg/L. After proper pretreatment of the water sample, The method can be used for the determination of ammonia nitrogen in surface water, groundwater, industrial wastewater, and domestic sewage.
