Ip68 Online Nitrogen Oxygen Sensor RS485 Modbus PLC DCS Connect

Product Details

Range:

0 ~ 10.00 Mg/L (0 ~ 100.00 Mg/L)

Resolution:

0.01 Mg/L

Precision:

± 10% Or ± 1mg/L

Operating Temperature:

0 ~ 40 °C

Working Pressure:

< 0.1 Mpa

The Ph Range Of The Medium:

4 ~ 10ph

Highlight:

PLC Connect Nitrogen Oxygen Sensor

RS485 Nitrogen Oxygen Sensor

Ip68 Nitrogen Oxygen Sensor

Payment & Shipping Terms

Minimum Order Quantity

0-100

Price

$0-$500

Packaging Details

Common package or custom package

Delivery Time

3-10days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100

KCW101 Frequency - Modulated Electromagnetic Wave Water Treatment Equipment

Get Best Price

KHM100 On - line Automatic Heavy Metal Water Quality Monitor

Get Best Price

KCW104 Automatic Softening Water Device

Get Best Price

KCW105 Ionization Water Purification Device

Get Best Price

86--17719566736

Contact Now

Product Description

Online Ammonia Nitrogen Sensor RS485 Modbus PLC DCS

Name: Ip68 Online Nitrogen Oxygen Sensor RS485 Modbus PLC DCS Connect
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KAN310
Price: 500 USD
Availability: InStock

1.Application Environment

KAN310 integrated on-line ammonia-nitrogen sensor is made of ammonium ion selective electrode based on PVC membrane, which is used to measure the content of ammonium ion in water with temperature compensation.

2.Feature

Signal Output: RS-485 bus, Modbus/RTU protocol,
Convenient to connect to PLC, DCS, Industrial Control Computer, General Controller, paperless recording instrument or touch screen and other third-party equipment.
The patented ammonium ion probe, with an internal reference fluid at a pressure of at least 100 kpa (1 bar), oozes extremely slowly from the microporous salt bridge. Such a reference system is very stable and the electrode life is longer than ordinary industrial electrode life.
Easy to install: submerged installation.
Ip68, containment level.

3.Technical Specifications

Model Number	KAN310
Range	0 ~ 10.00 mg/L (0 ~ 100.00 mg/L)
Resolution	0.01 MGL
Precision	± 10% or ± 1MG/L
Operating Temperature	0 ~ 40 °C
Working Pressure	< 0.1 mpa
The Ph Range Of The Medium	4 ~ 10ph
Temperature Compensation	Automatic temperature compensation (PT1000)
Power Supply	12 ~ 24 VDC ± 10%
Signal Output	RS-485 bus, Modbus/RTU protocol
Contact Material	PVC and POM
Installation Mode	Immersion mounting
Cable Length	5 meters, other length can be customized
Calibration Mode	Two-point calibration
Power Consumption	< 0.05 W
Protection Level	IP68

4.Dimensional Drawing

Ip68 Online Nitrogen Oxygen Sensor RS485 Modbus PLC DCS Connect 0

Tip:The difference between total nitrogen and ammonia nitrogen

Total nitrogen includes organic nitrogen, organic amines, amino acids, proteins, ammonia nitrogen, etc.

And ammonia nitrogen only includes NH4+ and NH3.

Ip68 Online Nitrogen Oxygen Sensor RS485 Modbus PLC DCS Connect 1
