Name: Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KUS550
Price: 1,000.10 USD
Availability: InStock

Home > products > Ultrasonic Transducer Sensor >

Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption

NPT Ultrasonic Water Level Sensor

Ultrasonic Water Level Meter

Place of Origin:

China (Mainland)

Brand Name:

Kacise

Certification:

certificate of explosion-proof, CE

Model Number:

KUS550

Request A Quote

Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption

Product Details

Response Time:

＜50ms

Beam Angle:

7°±2

Temp. Compensation:

Inside/outside/fix Temp.

Operating Voltage:

14.5VDC~27VDC

Output:

RS485,0~5V

Operating Ambient Temp.:

0~70℃ (-40~85℃, -55~125℃, Etc, Customizable)

IP Grade:

IP68

Detection Range:

200mm~3000mm

Transducer Frequency:

70KHZ

Repeatability Precision:

≤1%

Highlight:

NPT Ultrasonic Water Level Sensor

Ultrasonic Water Level Meter

Payment & Shipping Terms

Minimum Order Quantity

1pcs

Price

Negotiable

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal

Supply Ability

1000 Pieces per Week

KUS-W80 Underwater Distance Sensor 200kHz Transducer Frequency and Low No-load Current for Underwater Distance Measurement

Get Best Price

KUS-W50 Underwater Distance Sensor Reverse Polarity Protection And 0.6m Blind Area For Seamless Underwater Monitoring

Get Best Price

KWD200 Ultrasonic Underwater Communications Sensor

Get Best Price

High Accuracy KWD400 360-Degree Scanning Sonar Power Consumption ≤12W

Get Best Price

86--17719566736

Contact Now

Product Description

Anti Corrosion Chemical Liquid Measurement / NPT PTFE Ultrasonic Level Sensor for monitoring liquid levels and barns

KUS550 Ultrasonic Distance Sensor

1. Product features:

High sensitivity.
Compact and robust structure.
IP68 high protection rating.
Corrosion resistant casing, suitable for corrosive medium and application

Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption 0

2. Product Description

This sensor provides very short to long-range detection and ranging, in a compact, robust PVC housing,
designed to meet IP68.

Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption 1

3. Parameter

General specifications

Model: KUS550
Measuring range	0.25m~3m (5m customizable)KUS550A 0.15m-0.6m(1m customizable)KUS550B；
Blind spot	The dead zone of KUS550A is 0 ... 250 mm (within 250mm is unstable working zone, it is not recommended to work in this range); the dead zone of KUS550B is 0-150mm;
Supply voltage	3.3 ... 30 VDC, ripple 10 %SS
Working current	≤ 45 mA (fastest measurement speed), typical power consumption ≤ 10 mA;
Output signal	0-10V. 0-3V 0-5V /4-20mA/NPN/PNP/RS485 Analog output.
Measurement accuracy	≤1 %F.S.
Temperature compensation	Yes
Ranging resolution	0.1mm；

Working conditions

Working temperature	-40…85℃ (233...358K)
Storage temperature	-40…85℃ (233...358K)

Other instructions

Electrical connection	5-core cable (analog output), 6-core cable (switch output) .
Protection class	IP68
Shell material	PVC /PVDF/PTFE/ABS

Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption 2

4. Dimensions

Unit in the diagram is mm.

Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption 3

5. Wiring

Analogue output type wiring diagram

Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption 4

Switch output type wiring diagram

Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption 5

6. Application

Tank level measurement
Bin level measurement
Proximity zone detection
People detection
Robot ranging sensor
Autonomous navigation
Multi-sensors navigation
Distance measuring
Long range object detection
Industrial automation

7. Ordering information

8.Installation conditions
If the sensor is installed at the environment temperature fall below 0℃,It should do well on the protective measures. In case of direct mounting of the sensor in a through hole using the steel nuts, it has to be fixed at the middle of the housing thread.

Waterproof NPT PTFE RS485 Output Ultrasonic Water Level Sensor Low Power Consumption 6
