| Place of Origin: | Shaanxi, China |
| Brand Name: | KACISE |
| Model Number: | KMF-Series |
| Price: | $200.00 - $6,000.00/pieces |
|---|---|
| Packaging Details: | carton or customers requests available |
| Supply Ability: | 3000 Piece/Pieces per Week |
| Product Name: | Viscosity Mass Flow Meter | Measuring Range: | 0~1000kg/h |
|---|---|---|---|
| Diameter: | 3~250mm | Transmitter Output: | 4-20mA; 0-10KHz; RS485 Modbus RTU; HART |
| Pressure Rating: | 0~4.0MPa | Temperature Rating: | -50~350℃ |
| Accuracy Class: | 0.10~0.20% | Display: | LCD Display |
| Port: | Shanghai Or Other | ||
| High Light: | LCD Display Coriolis Flow Meter,High Viscosity Coriolis Mass Flow Meter,1000kg/H Coriolis Mass Flow Meter |
||
Coriolis Mass Flow Meters could directly measure the "Mass" of the liquid. And the accuracy is the highest among all types of flow meters, saying, ±0.1%~±0.2%. The range of application is very large, and it could be used for the medium that difficult to be measured, like, high temperature, high pressure, high viscosity, double phases, triple phases. The requirements for the installation are low, the straight pipe Requirements in front of and behind the Coriolis Mass Flow Meters are low.They are more reliable, stable, and the maintenance level is low.
Dimensions of large - scale instrument
|
Model |
Weld Neck Flanges-ANSI B16.5 |
A |
B |
C |
E |
F |
W |
G |
K |
d |
D |
|
|
|
DN |
LB |
|
|
|
|
|
|
|
|
|
|
|
KMF-1-6c |
100 |
150 |
670 |
510 |
740 |
858 |
1092 |
260 |
19.1 |
190.5 |
157.2 |
228.6 |
1.Q: May I put my own logo on the product?
A: Sure. Logo can be printed on the housing, and company name can be engraved on the nameplate.
2.Q: How about the quality control?
A: All products will be tested for 3 times before packed.
Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.
We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider.
