| Place of Origin: | Shaanxi, China |
| Brand Name: | KACISE |
| Model Number: | KMF |
| Price: | $200.00 - $6,000.00/pieces |
|---|---|
| Packaging Details: | Wooden crates or customer requirements |
| Supply Ability: | 3000 Piece/Pieces per Month negotiable |
| Product Name: | Titania Mass Flowmeter | Measuring Range: | 0-1000th/h |
|---|---|---|---|
| Temperature Rating: | -50℃~200℃ | Pressure Rating: | 0~4.0MPa |
| Mass Accuracy Grade: | 0.2 | Medium: | Gas And Air |
| Measuring Theory: | Coriolis Force | Display: | LCD Display |
| Port: | Shanghai Or Other |
Operating principle of Titania Mass Flowmeter
Titania Mass Flowmeter is designed according to Coriolis Effect. The inlet arm and the outlet arm vibrate with the same frequency as the overall vibration, but when there is mass flow the two vibrations are out of sync: the inlet arm is behind, the outlet arm is ahead. The two vibrations are shifted in phase with respect to each other, and the degree of phase-shift is a measure for the amount of mass that is flowing through the tubes.
Dimensions of large - scale instrument
|
Model | Weld Neck Flanges-ANSI B16.5 |
A |
B |
C |
E |
F |
W |
G |
K |
d |
D | |
|
| DN | LB |
|
|
|
|
|
|
|
|
|
|
| KMF-1-6c | 100 | 150 | 670 | 510 | 740 | 858 | 1092 | 260 | 19.1 | 190.5 | 157.2 | 228.6 |
1.Q: May I put my own logo on the product?
A: Sure. Logo can be printed on the housing, and company name can be engraved on the nameplate.
2.Q: How about the quality control?
A: All products will be tested for 3 times before packed.
3.Q: May I release trial order, 1 pc for example?
A: Certainly, trial order is acceptable. In general, we have common models in stock. Sample will be sent within 1 week, after payment is received.
We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.
Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.
