RS-485 Output Supports MODBUS's KWS201 On-line Ammonia Nitrogen Sensor

RS-485 Output Supports MODBUS's KWS201 On-line Ammonia Nitrogen Sensor

KWS201 ammonia nitrogen sensor

RS-485 ammonia nitrogen sensor

Place of Origin:

china

Brand Name:

KACISE

Certification:

CE

Model Number:

KWS-201

Contact Us
Request A Quote
Product Details
Measuring Range:
0-100mg/L (optional 0-1000mg/L)
Measurement Accuracy:
±10% Or ±0.5mg/L (whichever Is Greater)
Resolution:
0.01mg/L
Sensor Size:
φ36mm*265rmm (with Protective Cover)
Protection Level:
IP68
Sensor Interface:
Support RS-485, MODBUS Protocol
Assembly:
NPT3/4 Thread, Immersion Installation
Highlight:

KWS201 ammonia nitrogen sensor

,

RS-485 ammonia nitrogen sensor

Payment & Shipping Terms
Minimum Order Quantity
1PCS
Packaging Details
each unit has individual box and all boxes are packed in standard packages or customers requests available
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
1000 Piece/Pieces per Week negotiable
Product Description

Product Description

The KWS201 on-line ammonia nitrogen sensor, equipped with RS-485 output and support for MODBUS, is a state-of-the-art solution for water quality monitoring. This sensor offers seamless connectivity and integration into various monitoring systems. The RS-485 output provides reliable and efficient data transmission over long distances, while the MODBUS protocol allows it to communicate effortlessly with a wide range of devices and software. It is designed to be reagent-free, making it not only more economical but also environmentally friendly. The sensor's advanced technology enables it to automatically compensate for pH and temperature in water, ensuring accurate and precise measurements of ammonia nitrogen levels. Additionally, it features a self-cleaning brush that helps maintain its performance and extends its service life, reducing the need for frequent maintenance and downtime. With its high accuracy and reliability, the KWS201 is an ideal choice for applications such as industrial wastewater treatment, environmental monitoring, and aquaculture, where precise ammonia nitrogen detection is crucial for maintaining water quality and ensuring the health of aquatic ecosystems.
Feature

  • Automatically compensate for pH and temperature in water;
  • Ion electrode method, no electrolyte required, electrodes can be replaced separately, easy to maintain.
  • Digital sensor, RS-485 output, supports MODBUS;
  • No reagents required, no pollution, more economical and environmentally friendly;

Parameter

Name Ammonia Nitrogen sensor
Measuring range 0-100mg/L (optional 0-1000mg/L)
Measurement accuracy ±10% or ±0.5mg/L (whichever is greater)
Resolution 0.01mg/L
pH range 4-10pH
pH accuracy ±0.1pH
pH resolution 0.01
Sensor size φ36mm*265rmm (with protective cover)
Protection level IP68
Maximum depth 10 meters underwater
Temperature range 0-50℃
Sensor interface Support RS-485, MODBUS protocol
Assembly NPT3/4 thread, immersion installation
Power consumption 0.25W (recommended power supply: DC 9-24V, ≥1A)
Probe cable length 10 meters (default), customizable
Calibration 1-point or 2-point calibration
Casing POM+316L (customizable titanium alloy)
Dimension
