Name: KWS-850 Water Quality Sensor For Simultaneous Measurement Of Dissolved Oxygen / COD / Conductivity
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KWS-850
Price: 5,000.00 USD
Availability: InStock

Home > products > Water Quality Sensor >

KWS-850 Water Quality Sensor For Simultaneous Measurement Of Dissolved Oxygen / COD / Conductivity

COD Water quality sensor

Dissolved Oxygen Water quality sensor

Conductivity Water quality sensor

Place of Origin:

china

Brand Name:

KACISE

Certification:

Model Number:

KWS-850

Document:

KWS-850 Online Multi-Parame...al.pdf

Request A Quote

Product Details

Output:

RS-485(Modbus/RTU)

Cleaning Method:

Automatic Cleaning

Power Consumption:

5W@12V

Power Supply:

12VDC±5%

Accuracy:

±0.1pH

Highlight:

COD Water quality sensor

Dissolved Oxygen Water quality sensor

Conductivity Water quality sensor

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

KWS-850 Water Quality Sensor For Simultaneous Measurement Of Dissolved Oxygen / COD / Conductivity

Get Best Price

Video

The KWS-850 On-line Multi-parameter Water Quality Sensor Can Measure 8 Parameters Simultaneously

Get Best Price

Video

Power Consumption 5W 12V KWS-850 Multi-Parameter Water Quality Sensor For Water Monitoring

Get Best Price

Video

KWS-850 On-line Multi Parameter Sensor For Dissolved Oxygen And COD Measurement

Get Best Price

86--17719566736

Contact Now

Product Description

KWS-850 Water Quality Sensor For Simultaneous Measurement Of Dissolved Oxygen / COD / Conductivity

The KWS-850 Water Quality Sensor represents a revolutionary breakthrough in water analysis. This state-of-the-art device is engineered to simultaneously measure dissolved oxygen, COD (Chemical Oxygen Demand), and conductivity with remarkable precision. Its advanced sensing technology allows for real-time, accurate data collection, making it invaluable for environmental monitoring, industrial processes, municipal water treatment, and research laboratories.

Key Features

Digital sensor with RS-485 bus and Modbus/RTU communication protocol
Integrated design measures 8 parameters simultaneously (including temperature)
Optional digital sensors for dissolved oxygen, COD, conductivity/salinity, turbidity, ammonia nitrogen, pH, and ORP
Automatic cleaning device prevents microorganism attachment for more accurate measurements
Ideal for long-term online monitoring with reduced maintenance costs

Technical Specifications

Attribute	Value
Output	RS-485(Modbus/RTU)
Cleaning method	Automatic cleaning
Power consumption	5W@12V
Power supply	12VDC±5%
Accuracy	±0.1pH

Detailed Measurement Parameters

Dissolved Oxygen Probe

Measuring range	0～20mg/L
Accuracy	±0.4mg/L
Resolution	0.01mg/L

Turbidity Probe

Measuring range	Accuracy	Resolution
0～100NTU	±3% or ±2NTU	0.1NTU
0～1000NTU	±5% or ±3NTU	0.1NTU

Conductivity/Salinity Probe

Measuring range	Resolution
0～5000uS/cm	1uS/cm
0～200mS/cm	0.1mS/cm
0～70PSU	0.1PSU
Accuracy	±1.5% F.S.

COD Probe

Parameter	Measuring range	Accuracy	Resolution
COD	0～200mg/L equiv. KHP 0～500mg/L equiv. KHP	±5%F.S.	0.1mg/L
Turbidity	0～100NTU 0～200NTU	±5%F.S.	0.1NTU

pH Probe

Measuring range	0～14pH
Accuracy	±0.1pH
Resolution	0.01pH

ORP Probe

Measuring range	-1500mV～+1500mV
Accuracy	±6mV
Resolution	1mV

Ammonia Nitrogen Probe

Measuring range	0～100mg/L or 0～1000mg/L
Accuracy	±10% or ±2mg/L
Resolution	0.1mg/L

Temperature

Measuring range	0～50℃
Accuracy	±0.5℃
Resolution	0.1℃

Additional Specifications

Cable length	5 meters (customizable)

Product Dimensions

Installation Note: When installing the sensor for measurement, use lifting rings or pipe thread installation to avoid direct force on the cable. The sensor connector is M16-5 core waterproof male connector.

Application Examples
