Name: Reagent - Free Online Ammonia Nitrogen Sensor For Ammonia Nitrogen Monitoring In Urban Sewage Treatment Plants
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KWS-201
Price: 5,000.00 USD
Availability: InStock

Home > products > Water Quality Sensor >

Reagent - Free Online Ammonia Nitrogen Sensor For Ammonia Nitrogen Monitoring In Urban Sewage Treatment Plants

Online Ammonia Nitrogen Sensor

Reagent free Ammonia Nitrogen Sensor

Place of Origin:

china

Brand Name:

KACISE

Certification:

Model Number:

KWS-201

Request A Quote

Reagent - Free Online Ammonia Nitrogen Sensor For Ammonia Nitrogen Monitoring In Urban Sewage Treatment Plants

Product Details

Measuring Range:

0-100mg/L (optional 0-1000mg/L)

Measurement Accuracy:

±10% Or ±0.5mg/L (whichever Is Greater)

Sensor Interface:

Support RS-485, MODBUS Protocol

Assembly:

NPT3/4 Thread, Immersion Installation

Probe Cable Length:

10 Meters (default), Customizable

Highlight:

Online Ammonia Nitrogen Sensor

Reagent free Ammonia Nitrogen Sensor

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

KCW102 Low - Frequency Electromagnetic Wave Water Treatment Device

Get Best Price

KCW101 Frequency - Modulated Electromagnetic Wave Water Treatment Equipment

Get Best Price

KHM100 On - line Automatic Heavy Metal Water Quality Monitor

Get Best Price

KCW104 High - Efficiency Frequency - Sweeping Device

Get Best Price

86--17719566736

Contact Now

Product Description

Product Description

Our Reagent - free Online Ammonia Nitrogen Sensor is a game - changer in urban sewage treatment. Without the need for reagents, it's not only environmentally friendly but also cost - effective.

This sensor can continuously and accurately monitor the ammonia nitrogen content in influent, during treatment processes, and in the final effluent of urban sewage treatment plants. The real - time data it provides enables workers to promptly adjust treatment parameters. By doing so, it ensures that the treated sewage meets the discharge standards, effectively preventing water eutrophication. With its advanced technology, it offers reliable and stable performance, making it an essential tool for urban sewage treatment and environmental protection.

Feature

Digital sensor, RS-485 output, supports MODBUS;
Ion electrode method, no electrolyte required, electrodes can be replaced separately, easy to maintain.
No reagents required, no pollution, more economical and environmentally friendly;
Automatically compensate for pH and temperature in water;

Parameter

Name	Ammonia Nitrogen sensor
Measuring range	0-100mg/L (optional 0-1000mg/L)
Measurement accuracy	±10% or ±0.5mg/L (whichever is greater)
Resolution	0.01mg/L
pH range	4-10pH
pH accuracy	±0.1pH
pH resolution	0.01
Sensor size	φ36mm*265rmm (with protective cover)
Protection level	IP68
Maximum depth	10 meters underwater
Temperature range	0-50℃
Sensor interface	Support RS-485, MODBUS protocol
Assembly	NPT3/4 thread, immersion installation
Power consumption	0.25W (recommended power supply: DC 9-24V, ≥1A)
Probe cable length	10 meters (default), customizable
Calibration	1-point or 2-point calibration
Casing	POM+316L (customizable titanium alloy)
