Name: Class 2 Laser Grade RS232 High Accuracy Laser Distance Sensor for High Precision Measurements
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KLS210
Price: 5,000.00 USD
Availability: InStock

Home > products > Laser Sensors >

Class 2 Laser Grade RS232 High Accuracy Laser Distance Sensor for High Precision Measurements

High Accuracy Laser Distance Sensor

RS232 Laser Distance Sensor

High Precision Laser Distance Sensor

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

KLS210

Request A Quote

Class 2 Laser Grade RS232 High Accuracy Laser Distance Sensor for High Precision Measurements

Product Details

Measuring Range:

0.03~10m

Measuring Accuracy:

±1mm

Laser Grade:

Class 2

Laser Type:

620~690nm,<1mW

Working Voltage:

6~32V

Measuring Time:

0.4~4s

Highlight:

High Accuracy Laser Distance Sensor

RS232 Laser Distance Sensor

High Precision Laser Distance Sensor

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

KLSA Series Laser Ranging Sensors Maximum Measuring Distance 22m Enclosure Protection Level IP65 For Industry And Manufacturing

Get Best Price

Video

KLSA Series Laser Ranging Sensors Maximum Measuring Distance 22m Enclosure Protection Level IP65 For Industry And Manufacturing

Get Best Price

Video

KLSA Series Laser Ranging Sensors Maximum Measuring Distance 22m Enclosure Protection Level IP65 For Industry And Manufacturing

Get Best Price

KLSA Series Laser Ranging Sensors For Surveying And Engineering Construction

Get Best Price

Video

Outdoor High - Performance KLSA Laser Distance Sensor

Get Best Price

KL2A-25 2D laser radar for unmanned vehicles and unmanned ships

Get Best Price

86--17719566736

Contact Now

Product Description

RS232 High Accuracy Laser Distance Sensor

Introduction

Based on the laser ranging module, the KLS210 has added a protection device to avoid damage to the module, and can be used in more application scenarios. 10m measuring range, support RS232 data output.

Product Features

1. The minimum range is 3 cm, the maximum range is 10 meters (other ranges can be customized)

2. Frequency response 3Hz (other frequencies 8Hz, 20Hz, etc. can be selected or customized)

3. Resolution 1mm

4. Support multiple sensor networking

5. RS232 serial port interface, can support other interface communication such as TTL, RS485, Bluetooth, etc.

6. Non-contact precision measurement

Technical Parameters

Model	KLS210
Measuring Range	0.03~10m
Measuring Accuracy	±1mm
Laser Grade	Class 2
Laser Type	620~690nm,<1mW
Working Voltage	6~32V
Measuring Time	0.4~4s
Frequency	3Hz
Size	633012mm
Weight	20.5g
Communication Mode	Serial Communication, UART
Interface	RS232(TTL/USB/RS485/ Bluetooth can be customized)
Working Temperature	0~40℃(Wide temperature -10 ℃ ~ 50 ℃ can be customized)
Storage Temperature	-25℃-~60℃
