Stainless Steel Bellows Pressure Gauge with IP65 Protection and Bellows Sensing Element for Micro and Negative Pressure Measurement

The KMC-YE-100 stainless steel bellows pressure gauge utilizes a bellows element as a sensitive sensor for measuring micro pressure and negative pressure. Designed for applications requiring high corrosion resistance, it is ideal for measuring gaseous and liquid media in boiler ventilation systems, gas pipelines, combustion devices, and similar equipment.

The gauge is constructed with stainless steel for the pressure guiding system and housing, ensuring durability in corrosive environments. It measures pressure ranges from -1kPa to 205kPa with an accuracy grade of 2.5, making it suitable for non-explosive, non-corrosive (to copper alloys) media.

• Wide Measurement Range: -1kPa to 205kPa, suitable for micro pressure, negative pressure, and low-pressure applications
• High Corrosion Resistance: Stainless steel construction (pressure system and housing) for harsh environments
• IP65 Protection Grade: Dust-tight and protected against water jets from any direction, suitable for outdoor or dusty installations
• Bellows Sensing Element: Ensures sensitive response to tiny pressure changes with minimal hysteresis
• Easy On-Site Indication: Direct reading on a 100mm dial for immediate pressure monitoring
• Versatile Media Compatibility: Suitable for gases and liquids that are non-corrosive to copper alloys
