Place of Origin:
Shaanxi, China (Mainland)
Brand Name:
KACISE
Model Number:
K-2QJJ300/300D/500/500D
| Type | K-2QJJ300/300D | K-2QJJ500/500D |
| Electric character | ||
| Input voltage | 10~30VDC | |
| Input current | <40mA | <70mA |
| Output mode | RS485 | 4~20mA |
| Baud Rate | 19200 bps | - |
| Data updating | 25 Hz | - |
| Performance index | ||
| Range | ±20°,±40°,±60°,±75°selectable | |
| Nonlinear (%F.S.) | 0.1%F.S. | |
| Resolution (°/s) | 0.01° | |
| Bias | ≤0.2° | |
| Bandwidth | 5Hz | |
| Start-up time | <0.5s | |
| Environmental characteristics | ||
| Compensated Temperatures | -40℃~70℃ | |
| compensation temperature | -40℃~+70℃ | |
| Temperature (°C) | -40℃~+70℃ | |
| Storage Temperature | -40℃~+125℃ | |
| Physical Characteristics | ||
| Weight (g) | 250g | |
| Dimensions | 60×60×30mm | |
Note: Range can choose ±20°,±40°,±60°,±75°
When the company set up, we began to focus on the coordination of supplies production, achieved GB/T19001-2008/ISQ9001:2008, GJB 9001B-2009 certification. When our company is running mature and stable, in 2008, we began to develop our business. Based on the production of products quality control, we developed a lot of sensor products, such as a pressure sensor / transducer / sensor, level transmitter / ultrasonic level meter / ultrasonic flow meter, inertial navigation products, IMU, gyroscope, accelerometer etc.
