6 Bar Water Quality Sensor Four Electrode Digital Conductivity For Aquaculture

6 Bar Water Quality Sensor Four Electrode Digital Conductivity For Aquaculture

  • 6 Bar Water Quality Sensor Four Electrode Digital Conductivity For Aquaculture
  • 6 Bar Water Quality Sensor Four Electrode Digital Conductivity For Aquaculture
  • 6 Bar Water Quality Sensor Four Electrode Digital Conductivity For Aquaculture
  • 6 Bar Water Quality Sensor Four Electrode Digital Conductivity For Aquaculture
6 Bar Water Quality Sensor Four Electrode Digital Conductivity For Aquaculture
Product Details:
Place of Origin: China (Mainland)
Brand Name: Kacise
Certification: certificate of explosion-proof, CE
Model Number: KBU601
Payment & Shipping Terms:
Minimum Order Quantity: 0-100
Price: Negotiation
Packaging Details: each unit has individual box and all boxes are packed in standard packages or customers requests avai...
Delivery Time: 15
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100
Contact Now
Detailed Product Description
Accuracy: 1% Resolution: 1uS/cm
Response Time: <2 Sec Ip Grade: IP68
Maximum Operating Pressure: 6 Bar Temperature Range: 0~50℃
Output: RS-485, MODBUS Protocol Power Supply: DC 5~12V, <50mA
Temperature Sensor: NTC Electrode Material: Nickel
High Light:

water turbidity sensor

,

oil in water sensor



KWS-300 Digital Conductivity Sensor





Introduction



Kacise KWS-300 digital conductivity sensor with new generation of four-electrode / six-electrode
technology. Wide range of measurement, automatic switching measurement range, built-in temperature
sensor, Real-time temperature compensation. Excellent resistance to pollution, even in harsh
environments long-term online monitoring, there will be no polarization. RS485 output, can be networked
without controller





Feature



Digital sensor, RS485 output, support Modbus
Wide measuring range, automatic switching measurement range
Built-in temperature sensor, real-time temperature compensation
Four-electrode / six-electrode technology, no polarization




6 Bar Water Quality Sensor Four Electrode Digital Conductivity For Aquaculture 0



Specification



Item Four-electrode conductivity sensor Six-electrode condutivity sensor
Model KWS-301 KWS-302 KWS-303
Measuring Range 1uS/cm~200mS/cm 1uS/cm~100mS/cm 1uS/cm~100 mS/cm
Accuracy 1%
Resolution 1uS/cm
Response time <2 sec
Ip Grade IP68
Maximum operating pressure 6 bar
Temperature Range 0~50
Output RS-485, MODBUS protocol
Power Supply DC 5~12V, <50mA
Temperature Sensor NTC
Electrode material Nickel
Wetted Part Material PEEK
Sensor size Φ 22*146.5 mm Φ 22*140 mm
Cable Length Standard 10m, customizable 5m, 15m and 30m cables
Calibration Method One/Two-point calibration
