Waterproof 30mA Ultrasonic Transducer Sensor 3000mm Detection

Waterproof 30mA Ultrasonic Transducer Sensor 3000mm Detection

  • Waterproof 30mA Ultrasonic Transducer Sensor 3000mm Detection
Waterproof 30mA Ultrasonic Transducer Sensor 3000mm Detection
Product Details:
Place of Origin: China
Brand Name: Kacise
Certification: CE
Model Number: KUS650
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: carton/wooden case, or customers requests
Delivery Time: 5-8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 10000pcs/month
Contact Now
Detailed Product Description
Connection: 5 Pin Cable Power Consumption: ≤30mA
Detection Range: 200mm~3000mm Transducer Frequency: 125KHZ
Beam Angle: 7°±2 IP Grade: IP65
Weight: 100g
High Light:

30mA Ultrasonic Transducer Sensor

,

3000mm Detection Ultrasonic Transducer Sensor

,

IEC Waterproof Ultrasonic Transducer Sensor



KUS650 Ultrasonic Level Sensor



Introduction
This sensor provides very short to long-range detection and ranging, in a compact, robust PVC housing,
designed to meet IP65.



Applications
. Tank level measurement
. Bin level measurement
. Proximity zone detection
. People detection
. Robot ranging sensor
. Autonomous navigation
. Multi-sensors navigation
. Distance measuring
. Long range object detection
. Industrial automation



Parameters



Enter
Measured variable Liquid

level, material level



Maximum measuremen trange

1.2-30m (can be customized according to demand)



Output
Comprehensive accuracy ±0.15%FS/ 0.15℃
Temperature compensation -10℃~70℃
Vibration effects < ± 0.05%/g, 500Hz in all directions (according to IEC 68-2-64)

Rated conditions

environmental conditions

Ambient temperature -25~+85℃
Storage temperature -40~+85℃
Protection class IP68 , according to EN 60529
Electromagnetic Compatibility EN 61326/A2 Annex A (2001)
Display and control
Display SFTN liquid crystal, white backlight, 5-digit display.
Limit value Free setting
Parameter setting Use 3 buttons
Unit

The unit is mm, and the default unit is m.



Weight

about 1.35kg



Materials of non-wetted parts
Joint 1NPT, stainless steel, length 20mm (material and joint specifications can be customized according to customer requirements).
Electrical connection

Make waterproof connector, air vent cable entry according to EN 175301-803A standard



Measurement period ≤ 100ms

Selection Tips: For special requirements, please contact our company and indicate it in the order.



Features
. Designed for outdoor or indoor environments
. High sensitivity
. Free run operation can continually measure and output ranger information
. Sensor beam angle is 7 degrees.



Storage and transportation

1. The product should be stored at -40℃~+80℃, relative humidity not more than 90%, ventilated, dry and non-corrosive gas warehouse.

2. The product, the certificate of conformity and the instruction manual are packed in one package, and strong collision is strictly prohibited during transportation.

Note: The contents of the manual are subject to change without prior notice, please pay attention to keep in touch.



 Installation and maintenance



1. Installation

1) The instrument should be installed vertically and horizontally.

2) When using with other instruments, pay attention to the matching of the range.

3) Before installing the digital meter on the device, check whether the meter head is clean. During use, the pipeline should be kept clean.

2. Maintenance

1) The instrument is a high-precision instrument, and should be selected in a place with air circulation, easy observation, and easy maintenance and operation.

2) Although the digital sensor can exceed the range during use, long-term use will affect the accuracy of the measurement and may damage the meter. It is recommended that the user use the meter according to the range.

3) When the LCD screen of the wireless digital meter shows that the battery voltage is blank, please replace the battery to ensure the normal measurement.

Note: The rechargeable battery can only be charged, and the charging time is 3~4 hours.
