Name: KUS550 125KHZ Ultrasonic Level Sensor For Tank Level Measurement
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KUS550 Series
Price: 1,000.10 USD
Availability: InStock

Home > products > Ultrasonic Transducer Sensor >

KUS550 125KHZ Ultrasonic Level Sensor For Tank Level Measurement

KUS550 Ultrasonic Level Sensor

Tank Level Waterproof Ultrasonic Sensor

125KHZ Ultrasonic Tank Level Sensor

Place of Origin:

China

Brand Name:

Kacise

Certification:

Model Number:

KUS550 Series

Request A Quote

KUS550 125KHZ Ultrasonic Level Sensor For Tank Level Measurement

Product Details

Connection:

5 Pin Cable

Power Consumption:

≤30mA

Detection Range:

200mm~3000mm

Transducer Frequency:

125KHZ

Beam Angle:

7°±2

Protection:

IP65

Highlight:

KUS550 Ultrasonic Level Sensor

Tank Level Waterproof Ultrasonic Sensor

125KHZ Ultrasonic Tank Level Sensor

Payment & Shipping Terms

Minimum Order Quantity

1 Piece

Price

Negotiable

Packaging Details

carton/wooden case, or customers requests

Delivery Time

5-8 working days

Supply Ability

10000pcs/month

KUS-W80 Underwater Distance Sensor 200kHz Transducer Frequency and Low No-load Current for Underwater Distance Measurement

Get Best Price

KUS-W50 Underwater Distance Sensor Reverse Polarity Protection And 0.6m Blind Area For Seamless Underwater Monitoring

Get Best Price

KWD200 Ultrasonic Underwater Communications Sensor

Get Best Price

High Accuracy KWD400 360-Degree Scanning Sonar Power Consumption ≤12W

Get Best Price

86--17719566736

Contact Now

Product Description

KUS550 Ultrasonic Level Sensor

1.Applications

. Tank level measurement
. Bin level measurement
. Proximity zone detection
. People detection
. Robot ranging sensor
. Autonomous navigation
. Multi-sensors navigation
. Distance measuring
. Long range object detection
. Industrial automation

2.Introduction
This sensor provides very short to long-range detection and ranging, in a compact, robust PVC housing,
designed to meet IP65.

3.Electronic interface and signals definition

Switch output type wiring diagram

KUS550 125KHZ Ultrasonic Level Sensor For Tank Level Measurement 0

4.Features
. Designed for outdoor or indoor environments
. High sensitivity
. Free run operation can continually measure and output ranger information
. Sensor beam angle is 7 degrees.

5.Parameter

General specifications

Model: KUS550
Measuring range	0.25m~3m (5m customizable)KUS550A 0.15m-0.6m(1m customizable)KUS550B；
Blind spot	The dead zone of KUS550A is 0 ... 250 mm (within 250mm is unstable working zone, it is not recommended to work in this range); the dead zone of KUS550B is 0-150mm;
Supply voltage	3.3 ... 30 VDC, ripple 10 %SS
Working current	≤ 45 mA (fastest measurement speed), typical power consumption ≤ 10 mA;
Output signal	0-10V. 0-3V 0-5V /4-20mA/NPN/PNP/RS485 Analog output.
Measurement accuracy	≤1 %F.S.
Temperature compensation	Yes
Ranging resolution	0.1mm；

Other instructions

Electrical connection	5-core cable (analog output), 6-core cable (switch output)；
Protection class	IP67
shell material	PVC /PVDF/PTFE/ABS

6.Installation conditions

If the sensor is installed at the environment temperature fall below 0℃, It should do well on the protective measures. In case of direct mounting of the sensor in a through hole using the steel nuts, it has to be fixed at the middle of the housing thread.
