5V ultrasonic level meter for septic tank level measurement

5m Ultrasonic Transducer Sensor

5m Ultrasonic Level Transducer

5V Ultrasonic Level Transducer

Place of Origin:

China (Mainland)

Brand Name:

Kacise

Certification:

ce,ISO9001

Model Number:

KUS600

Document:

KUS600 series ultrasonic se....7.pdf

Request A Quote

Product Details

Product:

Ultrasonic Distance Sensor

Detection Range:

300mm~5000mm

Transducer Frequency:

Approx. 220kHz

Output:

RS485 + 4-20mA/0-10V

Input Power:

3.3V~24V

IP Grade:

IP68

Material:

PVDF

Type:

Waterproof

Theory:

Ultrasonic Sensor

Warranty:

12 Months

Product Name:

PVDF 5m Ultrasonic Water Level Meter

Highlight:

5m Ultrasonic Transducer Sensor

5m Ultrasonic Level Transducer

5V Ultrasonic Level Transducer

Payment & Shipping Terms

Minimum Order Quantity

1pcs

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5work days

Payment Terms

T/T, Western Union, MoneyGram

Supply Ability

1000 Pieces per Week

10mW Resolution KWD300 Ultrasonic Noise Detection Sensor for Precise Detection

Get Best Price

KWD200 Ultrasonic Underwater Communications Sensor

Get Best Price

KWD510 M26 Hydrophone

Get Best Price

86--17719566736

Contact Now

Product Description

5V ultrasonic level meter for septic tank level measurement

Name: 5V ultrasonic level meter for septic tank level measurement
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KUS600
Price: 1,000.10 USD
Availability: InStock

The 5V ultrasonic level meter is an essential device for septic tank level measurement. Operating at 5V, it emits ultrasonic waves to determine the liquid level within the septic tank. It provides accurate and real-time data, allowing for efficient management and timely maintenance. With its compact design and reliable performance, it is a practical solution for septic tank monitoring.

1. Dimensions

Unit in the diagram is mm.

2. Electronic interface and signals definition

Cable color	Pin	Description	Note
Red	1	Power supply
Black	2	GND
Yellow	3	Analogue output	The 600B will work in mode 1 or 0 cannot work in power save mode, if the 4-20mA, 0-3.3V 0-5V analogue output used.
Blue	4	RS485A+	TTL-TXD for ttl output signal
Green	5	RS485B-	TTL-RXD for ttl output signal

For switch output

Cable color	Pin	Description	Note
Red	1	Power supply
Black	2	GND
Yellow	3	Switch output	Load current 1A@60V
White	4	Switch output	Load current 1A@60V
Brown	5	RS485A+	TTL-TXD for ttl output signal
Green	6	RS485B-	TTL-RXD for ttl output signal

3. Parameter

General specifications

KUS600
Sensing range	600... 5000 mm@3.3V power supply. The measure distance can reach 6 meters if the power supply is 24V.
Adjustment range	300….5000mm
Unusable area	0 ... 600 mm
Response delay	approx. 10 ms
Material	PVDF

Electrical specifications

Operating voltage UB	3.3 ... 24 V DC , ripple 10 %SS
No-load supply current I0	≤ 20 mA active period and ≤0.3mA during sleep time

4. Installation conditions
If the sensor is installed at the environment temperature fall below 0℃,It should do well on the protective measures. In case of direct mounting of the sensor in a through hole using the steel nuts, it has to be fixed at the middle of the housing thread.

5V ultrasonic level meter for septic tank level measurement 1

Packing and shipping

5V ultrasonic level meter for septic tank level measurement 2
