GXB28-400 engine vibration isolators Shock Absorber Vehicle Ship Airborne Buffer with mounting holes M12

Product Description
The isolators offer threeplane, all-axis isolation that permits use in any attitude – vertically, horizontally and laterally. The large dynamic displacement attenuates heavy shocks, while the inherent damping provided by the sliding friction between the strands of the wire rope enable the GXB28 Series to minimize post-shock noise and lower resonant peaks.
The GXB28 Series isolators will function in any temperature from -400o F to +700o F. The isolators resist ozone, oil, grease, sand, salt spray and organic solvents – providing permanent solutions to any environmental demand. Once installed, the GXB28 Series need little or no maintenance and usually will outlast the protected equipment. Contact Kacise for special materials or mounting plates.
Product Size Chart


Press Fit Test Data Sheet


45° Inclined Press Fitting Load Test Data Sheet


Shear Rolling Load Test Data Sheet



Wire rope vibration isolators have the following advantages:

• Rugged, metal construction
• Low frequency, highly damped vibration isolation
• Excellent shock attenuation
• Wide temperature range, -400°F to +700°F
• Fail-safe construction
• Maintenance-free

Product structure diagram

Guide for installation of wire rope isolator
1. Before installation, please carefully check whether the mounting hole matches the mounting hole of the vibration isolator, such as whether the thread is the same, etc.
2, the installation hole is clean, there is no burr, rust, damage and other defects.
3. Since the vibration isolator is an elastic component, it needs a little movable space when working. Before installation, please carefully check whether there is any equipment affecting installation in the installation part and whether the movable space of the vibration isolator is enough. Please check whether the vibration isolator is in good condition and has no defects before installation.
4. Prepare a suitable screwdriver and crowbar.
5, first install the isolator to heavy equipment or fixed equipment, installation screws do not need to tighten, so that the isolator can be slightly active.
6. Install the connecting device on the other side of the vibration isolator. If the mounting hole is slightly misaligned, you can move the vibration isolator or use a crowbar to align the mounting hole of the vibration isolator with the mounting hole of the equipment, and then screw the fixing screw.
7. After fixing the device position, tighten all the fixing screws.
Application
