KUS640 Series Intelligent Ultrasonic Level Sensor 4 - 20mA Remote Transmission IP68

Remote Transmission Ultrasonic Level Sensor

Intelligent Ultrasonic Level Sensor

IP65 Fluid Level Meter

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

KUS640

Request A Quote

Product Details

Measured Variable:

Liquid Level, Material Level

Measuring Range:

150mm-1000mm（Can Be Customized According To Demand） 200mm-3000mm/300mm-6000mm/300mm-12000/600mm20000mm/1.2m-30m/1.8-50m

Comprehensi Ve Accuracy:

RS485/4-20mA，±1%FS/ 0.15℃

Temperature Compensation:

-10℃～70℃

Vibration Effects:

< ± 0.05％/g，500Hz In All Directions (according To IEC 68-2- 64)

Protection Class:

IP68 ，Complies With EN 60529

Highlight:

Remote Transmission Ultrasonic Level Sensor

Intelligent Ultrasonic Level Sensor

IP65 Fluid Level Meter

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Price

Negotiable

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

Product Description

KUS640 Series Intelligent Ultrasonic Level Sensor 4-20mA Remote Transmission IP68

Key Features

Power supply: 24VDC, customizable 12-24VDC
Special wide temperature LCD display (-30℃～80℃)
Vertical or axial installation with multiple liquid level interface options
Parameterizable LCD with three setting buttons

Technical Specifications

Attribute	Value
Measured variable	Liquid level, material level
Measuring range	150mm-1000mm (Customizable: 200mm-3000mm/300mm-6000mm/300mm-12000mm/600mm-20000mm/1.2m-30m/1.8-50m)
Comprehensive accuracy	RS485/4-20mA, ±1%FS/0.15℃
Temperature compensation	-10℃～70℃
Vibration effects	< ±0.05％/g, 500Hz in all directions (IEC 68-2-64 compliant)
Protection class	IP68 (EN 60529 compliant)

Applications

The KUS640 series monitors water pressure/level changes and transmits real-time data to centralized management platforms via built-in wireless modules. Ideal for:

Fire water systems
Municipal water supply
Wastewater treatment
District heating
Food processing
Chemical and energy industries

Additional Technical Parameters

Ambient temperature: -25～+85℃
Storage temperature: -40～+85℃
Display: SFTN LCD with green backlight, 5-digit
Weight: Approximately 1.35kg
Electrical connections: Waterproof connectors per EN 175301-803A

Important Notes

Instrument calibration must be performed by professionals only
Allow 1 hour warm-up time before calibration
Contact manufacturer for special requirements

Storage & Transportation

Store at -40℃~+80℃ with ≤90% relative humidity in dry, ventilated area
Avoid strong impacts during transportation

Note: Specifications subject to change without notice. Please maintain contact for updates.
