Name: KSINC01 Current Type Inclinometer
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KSINC01
Price: 1,000.00 USD
Availability: InStock

Home > products > Fluid Level Meter >

KSINC01 Current Type Inclinometer

Place of Origin:

CHINA

Brand Name:

kacise

Certification:

Model Number:

KSINC01

Request A Quote

Product Details

Supply Voltage (VDC):

9~36V (test Voltage: 12V)

Supply Current (mA):

<30

Measuring Range(°):

Single Axis, Dual Axis Optional 0~±90° Optional

Zero Position (V):

12mA±0.05

Full Scale Output:

4-20mA

Resolution:

0.001°

Highlight:

KSINC01 Current Type Inclinometer

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

Corrosion Resistant Capacitive Level Transmitter With NPN/PNP Output Is Used For Level Monitoring In Laboratory Reactors

Get Best Price

Video

KLD800 Series 80G Radar Level Gauge PTFE Antenna Size Small Blind Spot

Get Best Price

Video

0.1m~3m Capacitive Water Level Sensor High Performance And Wide Range

Get Best Price

1m Liquid Tank Level Sensor IP67 Fluid Level Meter RS485 Output

Get Best Price

86--17719566736

Contact Now

Product Description

KSINC01 Current Type Inclinometer

Key Specifications

Attribute	Value
Supply voltage (VDC)	9~36V (test voltage: 12V)
Supply current (mA)	<30
Measuring range(°)	Single axis, dual axis optional 0~±90° optional
Zero position (V)	12mA±0.05
Full scale output	4-20mA
Resolution	0.001°

Product Overview

The KSINC01 series inclinometer is a high-precision sensor designed for tilt measurement applications. Featuring instrument-level accuracy with current output, this sensor delivers exceptional reliability and stability across varying temperatures and extended periods of operation.

Key characteristics include:

High resolution measurement capability
Low noise operation
Exceptional overload resistance

Applications

Inclination measuring instruments
Position measurement systems
Acceleration and motion measurement
Automotive measurement and control
Inertial navigation systems
Earthquake monitoring equipment

Technical Parameters

Parameter	Specification
Model	KSINC01
Measurement accuracy	±15°<0.05° ±30°<0.08° ±45°<0.2°
Long term stability	<0.1°
Zero bias repeatability	<0.01°
Protection level	IP67
Working temperature (℃)	-40~+85
Storage temperature (℃)	-55~+85
Weight (g)	<150
Dimension (mm)	75×55×27

Dimensions
