Highly-Isolated XD5E Series Ethernet PLC Ambient Humidity 5%-95% no Condensation Isolation Above DC 500V 2MΩ

XD5E Series Ethernet PLC

Product Introduction

The XD5E series Ethernet PLC is a cutting-edge industrial automation solution, available in 24, 30, 48, and 60 I/O point models. Designed for seamless integration with existing systems, it fully inherits the capabilities of the XD5 series while adding Ethernet communication support. With a processing speed 12 times faster than the XC series and expanded internal resources, it excels in high-speed control tasks, making it ideal for complex industrial processes, robotics, and automation systems.

Key Features

• Ethernet Connectivity: Built-in RJ45 port enables easy integration with upper PCs, network monitoring, and communication with other devices, facilitating real-time data exchange and remote control.
• High-Speed Performance: Processes instructions in just 0.05 μs, 12 times faster than the XC series, ensuring rapid response to dynamic industrial environments.
• Abundant I/O Options: Multiple models with NPN input and transistor (T), relay (R), or mixed output types, catering to diverse control requirements.
• Versatile Expansion: Supports up to 16 expansion modules, 1 expansion ED, and 1–2 expansion BD, allowing flexible customization for complex applications.
• Specialized Functions: Offers high-speed counting (up to 80kHz), 2–10 axis pulse output (up to 100kHz), and frequency measurement for precise motion control and sensor interfacing.
• Reliable Design: DC 500V isolation and robust anti-noise protection (1000Vp-p, 1μs pulse) ensure stable operation in harsh industrial environments.
• Dual Communication Ports: RS232 (COM1) for programming and HMI connection; RS485 (COM2) for interfacing with intelligent instruments and inverters.

General Specifications

Functional Specifications
