Product Introduction

The Honeywell Sensepoint XCD CO Fixed Industrial Gas Detector (Model SPXCDALMCX) is a high-reliability solution designed for continuous monitoring of carbon monoxide (CO) in industrial environments. Equipped with Surecell™ electrochemical sensor technology, it ensures precise and responsive detection in harsh conditions, suitable for both indoor and outdoor applications. The detector features a robust explosion-proof housing (stainless steel or aluminum) with an IP66 rating, global safety certifications, and a user-friendly tri-color backlit display for real-time status monitoring. Its modular design allows for easy installation, non-intrusive maintenance, and flexible system integration, making it ideal for fixed gas detection in manufacturing, oil & gas, and commercial facilities.

Product Features

Precision CO Detection:

Utilizes Surecell™ electrochemical sensors for accurate CO measurement with fast response times.

Poison-resistant sensor design ensures long-term reliability and minimal false alarms.

Rugged Environmental Performance:

Operating temperature range: -40°C to 65°C (-40°F to 149°F) for extreme industrial conditions.

IP66 protection against dust and high-pressure water jets, suitable for outdoor installations.

Intuitive User Interface:

Tri-color backlit LCD (green/normal, yellow/fault, red/alarm) with numeric display, bar graph, and icons.

Non-intrusive configuration via magnetic switches (no need to open the housing).

Flexible Integration:

4–20 mA output (sink/source selectable) and MODBUS RTU communication for system integration.

Optional remote sensor mounting (up to 30m) for hard-to-reach detection points.

Global Safety Approvals:

Compliant with ATEX, IECEx, UL, CSA, CCCF, and other international standards for use in hazardous areas.

Explosion-proof design certified for potentially explosive atmospheres.

Cost-Effective Maintenance:

Plug-in sensor replacement and auto-inhibit function during adjustments to prevent false alarms.

Common transmitter platform reduces spare parts inventory and training requirements.

Easy Installation:

Integral mounting bracket for surface or pipe mounting (horizontal/vertical).

Removable terminal blocks and M20/NPT cable entries for simplified wiring.
