KMC-666 Digital Car Paint Thickness Gauge

KMC-666 Digital Car Paint Thickness Gauge

Product Introduction

The KMC-666 is a high-precision digital thickness gauge designed for non-destructive measurement of paint, coatings, and films on metal surfaces. With 2.5% accuracy, it efficiently detects paint thickness on ferrous and non-ferrous metals, making it essential for used car inspections, quality control, and manufacturing. The gauge automatically identifies magnetic (iron, steel) and non-magnetic (aluminum, copper) substrates, eliminating the need for manual mode switching. Its compact, battery-powered design (80g, 114×53×25mm) and -20°C to 50°C temperature tolerance ensure reliability in diverse environments, from automotive workshops to industrial facilities.

Product Features

Precision Measurement:

2.5% accuracy for reliable paint thickness detection (0–2000μm range).

Ideal for distinguishing factory paint (100–200μm) from repainted areas (500–1000μm).

Substrate Adaptability:

Auto-identifies magnetic (Fe, Ni) and non-magnetic (Al, Cu) substrates.

Measures non-conductive coatings on metal and non-ferromagnetic coatings on ferromagnetic metals.

Environmental Resistance:

Operates in -20°C–50°C with electrostatic and moisture resistance.

Suitable for harsh workshop conditions and outdoor use.

User-Friendly Design:

Compact, lightweight (80g) with battery power (auto-shutoff for energy saving).

Intuitive operation for quick measurements without complex settings.

Data Management:

Supports multi-point averaging (e.g., 5-point measurement on car doors) for accurate results.

Portable for on-site inspections in automotive, manufacturing, and quality control.

Technical Specs at a Glance
