| 3SE5234-1LC05-1AD5 |
Basic switch/complete switch, Plastic enclosure according to EN 50047, 31 mm, 1 NO/2 NC quick action contacts, with M12 connector 8-pole, Pin assignment: Pin1=21, Pin2=22, Pin3=13/LED green, Pin4=14/LED yellow, Pin5=31, Pin6=32, Pin7=LED ground, Pin8=Not assigned |
| 3SE5234-0LE11-1AE2 |
Position switch, plastic enclosure according to EN 50047, 31 mm, 1 NO/2 NC quick action contacts, with M12 plug, 5-pole, Pin assignment: Pin1=21, Pin4=22, Pin2=31, Pin5=32, for maximum 125 V and 4 A, roller lever with stainless steel roller 13 mm, suitable for connection to all SIMATIC ET 200 compact block I/O modules |
| 3SE5234-0LD03-1AE2 |
Position switch, plastic enclosure according to EN 50047, 31 mm, 1 NO/2 NC quick action contacts, with M12 plug, 5-pole, Pin assignment: Pin1=21, Pin4=22, Pin2=31, Pin5=32, for maximum 125 V and 4 A, roller plunger with plastic roller 10 mm, suitable for connection to all SIMATIC ET 200 compact block I/O modules |
| 3SE5234-0LC05-1AE2 |
Basic switch/complete switch, plastic enclosure according to EN 50047, 31 mm, 1 NO/2 NC quick action contacts, with M12 plug, 5-pole, 2 NC connected, Pin assignment: Pin1=21, Pin4=22, Pin2=31, Pin5=32, for maximum 125 V and 4 A, with Teflon plunger, suitable for connection to all SIMATIC ET 200 compact block I/O modules |
| 3SE5232-0HC05-1AB2 |
Position switch, Plastic enclosure 31 mm according to EN 50047, Control cabinet type, 1 NO/1 NC snap-action contacts integrated (not replaceable), Rounded plunger, Degree of protection IP40, with Self-sealing grommet, Cover flat (turquoise), With accessories: screws and mounting plate (without locking sheet metal and seal) |
| 3SX5100-1A |
Mounting plate for control cabinet position switch: 3SE5232-0CH05-1AB, 3SE523. (plastic 31 mm) and 3SE521. (metal 31 mm) |
| 3SE5232-0LE12 |
Position switch, Plastic enclosure according to EN 50047, 31 mm, Device connection: 1 x (M20 x 1.5), 1 NO/2 NC quick action contacts, Roller lever with stainless steel lever and plastic roller 13 mm |
| 3SE5232-0HC05-1AB4 |
Position switch, Plastic enclosure 31 mm according to EN 50047, Control cabinet type, 1 NO/1 NC snap-action contacts integrated (not replaceable), Rounded plunger, Degree of protection IP40, with Self-sealing grommet, Standard cover (turquoise), With accessories: screws and mounting plate (without locking sheet metal and seal) |
| 3SE5232-0HC05-1AB3 |
Position switch with plastic enclosure, Control cabinet type (without mounting plate), EN 50047, Device connection: 1 x (M20 x 1.5), 1 NO/1 NC snap-action contacts integrated (not replaceable), Rounded plunger, Degree of protection IP40, with Self-sealing grommet, Standard cover (turquoise), Without locking sheet metal, gasket and screws |
| 3SE5232-0HK15 |
Position switch, Plastic enclosure according to EN 50047, 31 mm, Device connection: 1 x (M20 x 1.5), 1 NO/1 NC quick action contacts integrated (not replaceable), Twist lever (35 mm long, right/left adjustable) with plastic roller 19 mm |
