Name: 2700 2800 Current to Pressure Transducer 4-20 mA Input NEMA 4X
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: 2700 and 2800
Price: 152.00 USD
Availability: InStock

Home > products > Precision Pressure Sensor >

2700 2800 Current to Pressure Transducer 4-20 mA Input NEMA 4X

4-20 mA pressure transducer

NEMA 4X pressure sensor

2700 current to pressure transducer

Brand Name:

Dwyer

Certification:

Model Number:

2700 and 2800

Request A Quote

2700 2800 Current to Pressure Transducer 4-20 mA Input NEMA 4X

Product Details

Input Signal:

4-20 MA.

AccuracySeries 2800:

±0.1% Of Span.

Electrical Connection:

1/2" Female NPT.

Pressure Connections:

1/4" Female NPT.

LinearitySeries 2700:

<±0.5% Of Span.

Weight:

Series 2700: 1.3 Lb (0.59 Kg); Series 2800: 0.8 Lb (0.37 Kg).

Highlight:

4-20 mA pressure transducer

NEMA 4X pressure sensor

2700 current to pressure transducer

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

Honeywell STT850 Precision Pressure Transmitter for Industrial Use

Get Best Price

YOKOGAWA Digital YEWFLO Vortex Flowmeter With FOUNDATION Fieldbus

Get Best Price

Yokogawa FLXA202 2-Wire Dual Channel Transmitter Analyzer

Get Best Price

Yokogawa EJA430E Gauge Pressure Transmitter 4-20mA Output

Get Best Price

86--17719566736

Contact Now

Product Description

2700 2800 Current to Pressure Transducer 4-20 mA Input NEMA 4X

Product Attributes

Attribute	Value
Input Signal	4-20 MA.
AccuracySeries 2800	±0.1% Of Span.
Electrical Connection	1/2" Female NPT.
Pressure Connections	1/4" Female NPT.
LinearitySeries 2700	<±0.5% Of Span.
Weight	Series 2700: 1.3 Lb (0.59 Kg); Series 2800: 0.8 Lb (0.37 Kg).

Product Description

Series 2700 & 2800 Current to Pressure Transducer

Product Introduction

The Series 2700 and 2800 Current to Pressure Transducers are precision devices designed to convert variable current signals (4-20 mA) into proportional pneumatic outputs, ideal for controlling valve actuators, pneumatic positioners, and other industrial pneumatic equipment. Both series feature rugged NEMA 4X (IP65) enclosures for indoor/outdoor use and hold FM/CSA approvals for intrinsically safe operation. While the 2700 focuses on cost-effectiveness and high flow capacity, the 2800 incorporates advanced closed-loop feedback for enhanced stability in demanding environments.

Features

Economical Performance: Combines low startup cost, minimal air consumption (0.03 scfm at midrange), and reliable operation, making it a cost-effective choice for standard applications.
Versatile Plumbing: Input and output ports on both front and back enable flexible installation (remote or panel mounting).
High Flow Capacity: Integral volume booster delivers up to 12.0 scfm (at 100 psig supply), accelerating control speed in critical systems.
Easy Calibration: External zero and span adjustments simplify field calibration.
Intrinsically Safe: FM/CSA approved for Class I, II, III hazardous locations, ensuring safe use in explosive environments.

Technical Specs at a Glance

Parameter	Series 2700	Series 2800
Input Signal	4-20 mA	4-20 mA
Air Supply	5-100 psig (0.3-6.9 bar)	5-100 psig (0.3-6.9 bar)
Output Ranges	3-15 psig (0.2-1.0 bar); 6-30 psig (0.4-2.1 bar)	3-15 psig (0.2-1.0 bar); 6-30 psig (0.4-2.1 bar)
Enclosure	NEMA 4X (IP65), chromate-treated aluminum	NEMA 4X (IP65), chromate-treated aluminum
Connections	1/4" female NPT (pressure); 1/2" female NPT (electrical)	1/4" female NPT (pressure); 1/2" female NPT (electrical)
Agency Approvals	CE, FM, CSA (intrinsically safe)	CE, FM, CSA (intrinsically safe)
