Non Contact Fluid Level Meter Ultrasonic liquid level transmitter IP65 Protection Grade
Principle
The Non-Contact Fluid Level Meter, an ultrasonic liquid level transmitter, offers outstanding performance. With an IP65 Protection Grade, it is highly resistant to dust and water ingress. It utilizes ultrasonic technology to measure fluid levels without physical contact, ensuring accurate and reliable readings in a wide range of industrial and commercial applications.
Introduction
KUM series ultrasonic level meter is a kind of high precision liquid level sensor, using non-contact measurement, support for remote monitoring, measuring range is far small blind area, it can be used to detect transparent or colored objects, metal objects or non-metal objects, as well as solid, liquid or powdered substances. Environmental conditions such as smoke, dust, environment or rain have little influence on the detection performance of ultrasonic sensors. Widely used in tank liquid level measurement, food industry material measurement, chemical industry, metallurgy, machinery manufacturing, construction engineering and other industries.
Features
Non-contact measurement
Short response time
With display
Various output optional: switch, analog, or RS485
Level value output or distance output
Parameters
| Range |
Min. 0.5m, Max. 60m |
| Resolution |
3mm or 0.1%(which is bigger) |
| Response time |
< 200ms |
| Display |
Optional |
| Analog output |
4～20mA |
| Switch output |
Relay(optional) |
| RS232/485 |
MODBUS protocol or customized protocol (optional) |
| Power supply |
5VDC, 10~30VDC. 220VAC |
| Ambient temperature |
-20～+70℃ (-40~85℃, -55~125℃, etc, customizable) |
| Protection Class |
IP65 (IP66 is optional) |
FAQ
1. Q: What information need to be provided to choose the suitable model?
A: Please provide us: application field, range , output signal, medium, power supply, so we can choose model and quote for you quickly.
2. Q: Are you a trade company or a manufacturer?
A: We are an ISO approved manufacturer specialized in level and flow measuring instruments.
OEM & ODM service are available. Welcome to visit us.
3. Q: What is your MOQ?
A: To start our cooperation, sample order is acceptable.
4. Q: What is your delivery date?
A: The delivery date is about 3-15 working days after receipt of payment.
5. Q: What is your payment terms?
A: We support T/T, PayPal and Trade Assurance.
For mass production order, it is 30% deposit in advance and 70% balance before shipment.
6. Q: What is Trade Assurance payment method:
A: It’s a free service which can protect your orders from payment to delivery.
And we now have USD104,000.00 of caution money to assure your orders.
7. Q: Do you have a warranty?
A: Yes, we have the warranty of 12 months.
