Name: KLD805 Liquid Wired Radar Type Level Sensor For Continuous Level Measurement
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KLD805
Price: 1,000.00 USD
Availability: InStock

Home > products > Fluid Level Meter >

KLD805 Liquid Wired Radar Type Level Sensor For Continuous Level Measurement

Continuous Level Measurement Radar Sensor

IP67 Wired Radar Level Sensor

PTFE Liquid Radar Type Level Sensor

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

KLD805

Request A Quote

Product Details

Medium:

Strong Corrosive Liquid, Steam, Foam, High Temperature. And High Pressure

Measuring Range:

0.1m~10/20/30/60/100m

Process Connection:

Flange ≥ DN80

Process Temperature:

-40～200℃

Process Pressure:

-0.1～2.5MPa

Antenna Size:

76mm Lens Antenna (according To Flange Size)

Antenna Material:

PTFE/overall Filling

Accuracy:

±1mm

Protection Class:

IP67

Center Frequency:

80GHz

Launch Angle:

3°

Power Supply:

DC24V/DC12~24V /AC220V

Casing:

Aluminum / Plastic / Stainless Steel

Signal Output:

4...20mA/HART Protocol/RS485 Modbus

Highlight:

Continuous Level Measurement Radar Sensor

IP67 Wired Radar Level Sensor

PTFE Liquid Radar Type Level Sensor

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

KDI Series Display Controller Supporting Multi - Machine Communication

Get Best Price

Video

KDI Series Display Controller with Open Internal Parameter Setting Interface High Accuracy and 0.1 Resolution

Get Best Price

Video

Accurate KDI Series Measurement Display Controller with Multiple Index Input Switching and Temperature Compensation

Get Best Price

Video

KDI Series Light Column Display Controller With Digital And Analog Measurement

Get Best Price

86--17719566736

Contact Now

Product Description

KLD805 80G FM Radar Level Sensor

Introduction

KLD805 radar level sensor is very suitable for non-contact level measurement in simple applications with high protection requirements. Typical applications are water treatment, pump station, rainwater overflow tank, open channel flow measurement and water level monitoring.

Feature

Exact measurement results independent of medium, process and environmental conditions
Maintenance-free operation due to non-contact 80 GHz radar technology
High accuracy and reliability

KLD805

KLD805 Liquid Wired Radar Type Level Sensor For Continuous Level Measurement 0

Medium: strong corrosive liquid, steam, foam,

high temperature. and high pressure

Measuring range: 0.1m~10/20/30/60/100m

Process connection: flange ≥ DN80

Process temperature: -40～200℃

Process pressure: -0.1～2.5MPa

Antenna size: 76mm lens antenna (according to flange size)

Antenna material: PTFE/overall filling

Accuracy: ±1mm

Protection class: IP67

Center frequency: 80GHz

Launch angle: 3°

Power supply: two-wire /DC24V

four-wire /DC12~24V

four-wire /AC220V

Casing: aluminum / plastic / stainless steel

Signal output: two-wire /4...20mA/HART protocol

four-wire 4...20mA/ RS485 Modbus

Installation

1.Flange Installation

When using flange installation, the minimum distance between the instrument and the tank wall should be 200mm.

① datum plane

② vessel center or axis of symmetry

2.Hoisting Installation

Installation Requirements

When installing the instrument, avoid installing it above the material inlet, and try to avoid various objects that affect the signal, such as stirring paddles, etc.

KLD805 Liquid Wired Radar Type Level Sensor For Continuous Level Measurement 5

Under extremely complex working conditions, the instrument can work normally if there is no obstacle in the area with a radius of 20cm centered on the installation point.

KLD805 Liquid Wired Radar Type Level Sensor For Continuous Level Measurement 8

Installation connection diagram:

The maximum installation spool height H max depends on the installation spool diameter D and the size of the product launch angle.

Too long installation connection will affect the radar performance.

KLD805 Liquid Wired Radar Type Level Sensor For Continuous Level Measurement 9

Dimensions

Casing Dimension
Unit in mm:

KLD805 Liquid Wired Radar Type Level Sensor For Continuous Level Measurement 10

Production:
