GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C

GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

CE

Model Number:

GXPS

Contact Us
Request A Quote
GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C
Product Details
Accuracy:
0.25%, 0.5%, 1.0%
Temperature:
Customized Available
Name Transducer:
Level Transducer
Medium:
Oil ,water, Fuel ,waste Water, Sea
Product Name:
GP2014 GPS Tracker Fuel Level Sensor
Port:
Shanghai Or Other
Payment & Shipping Terms
Minimum Order Quantity
1PCS
Price
$50.00 - $180.00/pieces
Packaging Details
each unit has individual box and all boxes are packed in standard packages or customers requests available
Delivery Time
5-8 work days
Payment Terms
T/T, Western Union, MoneyGram
Supply Ability
1000 Piece/Pieces per Week negotiable
RELATED PRODUCTS
Good price KDI Series Display Controller Supporting Multi - Machine Communication online Video

KDI Series Display Controller Supporting Multi - Machine Communication

Get Best Price
Good price KDI Series Display Controller with Open Internal Parameter Setting Interface High Accuracy and 0.1 Resolution online Video

KDI Series Display Controller with Open Internal Parameter Setting Interface High Accuracy and 0.1 Resolution

Get Best Price
Good price Accurate KDI Series Measurement Display Controller with Multiple Index Input Switching and Temperature Compensation online Video

Accurate KDI Series Measurement Display Controller with Multiple Index Input Switching and Temperature Compensation

Get Best Price
Good price KDI Series Light Column Display Controller With Digital And Analog Measurement online Video

KDI Series Light Column Display Controller With Digital And Analog Measurement

Get Best Price
Contact Us
86--17719566736
Contact Now
Product Description
GP2014 GPS tracker fuel level sensor


1. Specification of different types of level sensors :

Spec. Numerical value Remark
Pressure range 0~1……500mH2O 1mH2O≈9.81kPa
Overload pressure 1.5times Rated pressure
fracture pressure 3 times rated pressure
Accuracy 0.25%F.S, 0.5%F.S, 1.0%F.S

Stability Typical value: 0.1%F.S   Max.: 0.2% F.S/year
Operating Temperature -40°C~85°C  or -40 °C  ~125 °C
compensation temperature -10°C~70°C
medium compatibility All Caustic Medium Compatible with 1Cr18Ni9Ti and 316L
electrical properties 2 line 3 line
Output signal 4~20mA 0~5V 0~10V
Power supplies 10~30Vdc 80~30Vdc/ac 11~30Vdc/ac Vdc/ac
load resistance (U-10)/0.02( Ω ) more than 100k Ω
insulation more than 100M Ω @50V
Electrical Connections waterproof fixed cable + Two rectangle circle+Sealing Rings+seal gum+ Pure glue   protection grade : IP68
pressure interface G1/4,input type
response time 10ms
Electric strength 500Vac@1 second
Graduate Certificate Programs certificate of explosion-proof, CE
electromagnetic compatibility electromagnetic radiation EN50081-1/-2, electromagnetic susceptibilty: EN50082-2
lightning protection air conduction resistance 8000V,case, cable conduction



2. Feature of different types of level sensors :



1). Diffused-Silicon oil filled core

2). All kinds of structure to satisfy different users

3). Easy to use with submersible measuring

4). Multiple pressure range and signal output

5). Non-polar 2 wire system current output

6). Can be used in lightning protection products

7). Reinforcing rib of liquid cable

8). Intrinsically safe explosion proof, Isolation explosion proof, CE



3. Application:



1). Deep well level measuring

2). Hydrologic measurement for river, lake, sea

3). Sewage treatment

4). Cloudy level measuring

5). Fluid reservoir level measuring

6). Water-saving irrigation

7). Circulating liquid consumption monitoring

8). Diversion works



4. Electric connection & structure



GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 0

GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 1GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 2




5. Package



GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 3GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 4GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 5GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 6GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 7



6. Product picture
GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 8
GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 9

GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 10
GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 11
GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 12
GP2014 GPS tracker fuel level sensor with compensation temperature -10°C~70°C 13








Please send us emali for more information.

In order to choose the suitable products for you, please send us below information with the feedback.



1. pressure range
2. accuracy
3. output signal
4. power supply voltage
5. pressure port
6. cable length

7. medium
8. temperature range



******************************************************************************************************************************************
