KWL801B Radar Level Transmitter 0.06m-40m Measurement Range Modbus/Text Protocol RS485 Communication

Product Description:

The KWL801B-RS485 radar level sensor is a level meter that conforms to the specific standards outlined in national standard DB50/T 826-2017. The sensor's core component is designed to be fully sealed, making it waterproof with an IP68 rating.

With a maximum measurement range that extends up to 40 meters, this sensor also has a minimal blind spot of less than 6 cms. The KWL801B-RS485 is highly accurate due to its higher frequency and broader bandwidth.

This product also includes a fixed bracket for easy installation and setup.

Features:

• Based on the self-developed CMOS millimeter-wave RF chip
• More compact RF architecture
• Higher signal-to-noise ratio
• Smaller dead zone
• 5GHz working bandwidth
• Higher measurement resolution and measurement accuracy
• Less influence by the interference in the installation environment
• More convenient of installation and
• Modern design of integrated flat antenna

Technical Specifications:

Wiring Instructions

Dimension:

Installation:

(1) Ensure that the sensor is perpendicular to the medium surface.

(2) Avoid the transmitting beam from irradiating interference objects and generating false echoes.

See the following for typical working conditions:

Applications:

Applications:

A radar level sensor functions by utilizing a principle known as time domain reflection (TDR). The sensor emits an electromagnetic pulse that travels through a cable or probe at the speed of light. When this pulse reaches the surface of the measured medium, a portion of the pulse is reflected back to the meter, creating an echo that travels back to the pulse transmitter through the same path.

The time it takes for the pulse to travel between the transmitter and surface of the measured medium is directly proportional to the distance between the two. As a result, the height of the level can be calculated accurately.

The accuracy of radar level sensors primarily relies on the quality of the signal emitted from the transmitter, as well as the reliability of the electronic components used in processing the reflected signal.
