Name: RS485 Output Corrosion Resistant Water Level Meter for IoT Water Level Monitoring KUS550A Measuring Range 0.25m-3m 5m Customizable
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KUS550
Price: 1,000.00 USD
Availability: InStock

Home > products > Fluid Level Meter >

RS485 Output Corrosion Resistant Water Level Meter for IoT Water Level Monitoring KUS550A Measuring Range 0.25m-3m 5m Customizable

IoT Water Level Meter

RS485 Output Water Level Meter

3m Water Level Meter

Place of Origin:

CHINA

Brand Name:

KACISE

Certification:

Model Number:

KUS550

Request A Quote

Product Details

Measuring Range:

0.25m~3m （5m Customizable）KUS550A； 0.15m-0.6m（1m Customizable）KUS550B

Blind Spot:

The Dead Zone Of KUS550A Is 0 ... 250 Mm (within 250mm Is Unstable Working Zone, It Is Not Recommended To Work In This Range); The Dead Zone Of KUS550B Is 0-150mm;

Supply Voltage:

3.3 ... 30 VDC, Ripple 10 %SS

Working Current:

≤ 45 MA (fastest Measurement Speed), Typical Power Consumption ≤ 10 MA;

Output Signal:

0-10V. 0-3V 0-5V /4-20mA/NPN/PNP/RS485 Analog Output.

Measurement Accuracy:

≤1 %F.S.

Temperature Compensation:

Yes

Ranging Resolution:

0.1mm

Highlight:

IoT Water Level Meter

RS485 Output Water Level Meter

3m Water Level Meter

Payment & Shipping Terms

Minimum Order Quantity

1PCS

Price

Negotiable

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

KDI Series Display Controller Supporting Multi - Machine Communication

Get Best Price

Video

KDI Series Display Controller with Open Internal Parameter Setting Interface High Accuracy and 0.1 Resolution

Get Best Price

Video

Accurate KDI Series Measurement Display Controller with Multiple Index Input Switching and Temperature Compensation

Get Best Price

Video

KDI Series Light Column Display Controller With Digital And Analog Measurement

Get Best Price

86--17719566736

Contact Now

Product Description

4-20mA output corrosion-resistant water level meter for iot water level monitoring

Features

High sensitivity.

Compact and robust structure.

IP68 high protection rating.

Corrosion resistant casing, suitable for corrosive medium and application

The 4 - 20mA output corrosion-resistant water level meter is an essential device for IoT water level monitoring. It is specifically designed to resist corrosion, allowing it to function reliably in various harsh water environments. The 4 - 20mA output signal is widely adopted in industrial control systems, providing a stable and proportional current that corresponds to the water level. This makes it convenient for integration with other IoT-enabled equipment and data acquisition systems. Through continuous and accurate water level measurement, it enables real-time monitoring and data analysis. It is applicable in numerous scenarios such as water storage tanks, sewage treatment plants, and river level monitoring, playing a crucial role in optimizing water resource management and ensuring the safety and efficiency of water-related operations.

Dimension

Unit in the diagram is mm.

Parameter

General specifications

Measuring range	0.25m~3m (5m customizable)KUS550A 0.15m-0.6m(1m customizable)KUS550B
Blind spot	The dead zone of KUS550A is 0 ... 250 mm (within 250mm is unstable working zone, it is not recommended to work in this range); the dead zone of KUS550B is 0-150mm
Supply voltage	3.3 ... 30 VDC, ripple 10 %SS
Working current	≤ 45 mA (fastest measurement speed), typical power consumption ≤ 10 mA
Output signal	0-10V. 0-3V 0-5V /4-20mA/NPN/PNP/RS485 Analog output
Measurement accuracy	≤1 %F.S.
Temperature compensation	Yes
Ranging resolution	0.1mm

Working conditions

Working temperature	-40…85℃(233...358K)
Storage temperature	-40…85℃(233...358K)

Other instructions

Electrical connection	5-core cable (analog output), 6-core cable (switch output)
Protection class	IP68
Shell material	PVC /PVDF/PTFE/ABS

Company Information

RS485 Output Corrosion Resistant Water Level Meter for IoT Water Level Monitoring KUS550A Measuring Range 0.25m-3m 5m Customizable 1
Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.
We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.
Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.

RS485 Output Corrosion Resistant Water Level Meter for IoT Water Level Monitoring KUS550A Measuring Range 0.25m-3m 5m Customizable 2

RS485 Output Corrosion Resistant Water Level Meter for IoT Water Level Monitoring KUS550A Measuring Range 0.25m-3m 5m Customizable 3
